About ARNOLD UMFORMTECHNIK GmbH & Co.KG
Who we are
The ARNOLD GROUP stands for intelligent and pioneering fastening technology worldwide. Based on many years of expertise in the production of highly complex extruded parts and innovative fasteners, ARNOLD has long since established itself as a comprehensive system provider and development partner for integrated fastening solutions. The BlueFastening Systems philosophy emphasises this holistic approach: the close integration of engineering, high-quality fasteners, precise functional parts and state-of-the-art feeding and processing technology ensures maximum efficiency, sustainability and global innovative strength - all from a single source. ARNOLD has been part of the Würth Group since 1994 and is driving the future of fastening technology with maximum precision and innovative strength.
1 / 2
2 / 2
Forchtenberg, Germany
Member since 2007
Premium Member since 2025
Employees> 1000
Certificates4
Turnover100 - 500 Mil.
Year of foundation1898
Competencies
Technologies
Additive Manufacturing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Fused deposition modelling (FDM) | 1–10 M | 1–300 mm | 1–300 mm | 1–300 mm | — | — | — |
Metal laser sintering | 1–1 M | 1–300 mm | 1–300 mm | 1–300 mm | — | — | — |
Multi-jet modelling (MJM) | 1–1 M | 1–300 mm | 1–300 mm | 1–300 mm | — | — | — |
3D printing (general) | 1–10 M | 1–300 mm | 1–300 mm | 1–300 mm | — | — | — |
Selective Laser Melting (SLM) | 1–10 M | 0.1–275 mm | 0.1–275 mm | 0.1–420 mm | 0.1–275 mm | 0–250 kg | 0.1–420 mm |
Selective laser sintering | 1–10,000 | 1–300 mm | 1–300 mm | 1–300 mm | — | — | — |
Stereolithography (SLA) | 1–10,000 | 1–300 mm | 1–300 mm | 1–300 mm | — | — | — |
Turning
| Technologies | Lotsize | Length | Diameter |
|---|---|---|---|
Turning | 1–50 M | 1–200 mm | 1–100 mm |
Automatic turning (bar) | from 1 | 1–800 mm | 1–250 mm |
Full-range turning (including milling) | 1–10 M | 1–500 mm | 1–350 mm |
Sheet Metal Forming (Stamping, Deep-drawing)
| Technologies | Lotsize | Length | Width | Material thickness |
|---|---|---|---|---|
Punching / pressing (Out-of-tool) | from 1 | 1–100 mm | 1–500 mm | 1–5 mm |
Assembly Group Manufacturing
| Technologies | Lotsize | Length | Width | Material thickness |
|---|---|---|---|---|
Clinching | 1–10 M | 1–1,000 mm | 1–500 mm | 1–30 mm |
Riveting | 1–10 M | 1–1,000 mm | 1–500 mm | 0.5–30 mm |
Assembly
| Technologies | Weight |
|---|---|
Mechanical assembly | 0–10 kg |
Industrial / On-site-assembly | 0–10 kg |
Solid Forming
| Technologies | Lotsize | Length | Diameter |
|---|---|---|---|
Impact extrusion | 1–50 M | 1–150 mm | 1–50 mm |
Heat Treatment
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|---|
Case hardening/surface hardening | 1–10 M | 1–120 mm | 1–12 mm | 1–12 mm | 1–12 mm | 0–0.05 kg |
Hardening and tempering | 1–10 M | 1–120 mm | 1–12 mm | 1–12 mm | 1–12 mm | 0–0.05 kg |
Surface Treatment
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Pickling | 1–10 M | 1–120 mm | 1–12 mm | 1–12 mm | — | 0–0.05 kg | — |
Electroplating | 1–10 M | 1–120 mm | 1–12 mm | 1–12 mm | — | 0–0.05 kg | — |
Galvanizing | 1–10 M | 1–120 mm | 1–12 mm | 1–12 mm | 1–12 mm | 0–0.05 kg | 1–12 mm |
Materials
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelCold extruding steel
Heavy metals
Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloys
Light metals
Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys
Industries
Paper and printing machinery industryMechanical engineeringHydraulic and pneumatic industryBoiler, container and tank construction Information technology (hardware)Household appliance industryPrecision engineering, mechatronics and opticsPower generation and transmission industryRailway and rail vehicles industryChemical industryOffice machinery and suppliesMining and tunnel engineeringLighting industryConstruction and architectural suppliesBuilding, agricultural and forestry machinery manufacturingAutomation and control engineeringFittings engineeringApparatus engineeringPlant engineering and constructionAerospace and aviation industryMedical technologyMeasurement and control technique, laboratory equipmentMilitary engineeringFurniture industryClean room technologyShipbuilding industrySpecial purpose machinery manufacturingTelecommunication industryPackaging industryMachine tool manufacturingDrive and gear engineeringElectrical industryAutomotive and vehicle constructionAir conditioning, refrigeration and ventilation industry
Certificates
ISO 9001:2015
ISO 14001
ISO-TS 16949:2009
IATF 16949:2016
Contact
Location
Main locationCarl-Arnold-Str.25, 74670 Forchtenberg, Germany
Further locationsDörzbach, Forchtenberg-Rauhbusch
