About Braitinger GmbH Laser-und Metalltechnik
Who we are
We manufacture your items and series with our wide machines as eg laser cutting machines, press brakes, bending machines, welding robots, saws, etc. in the materials steel, stainless steel and aluminum; mount your module and pack them on request. Through continuous investment in the latest machine technologies and highly qualified motivated permanent staff as well as flexible working hours, we offer our long-time customers of the highest quality to attractive prices Challenge us, we will gladly process your request.
1 / 3
2 / 3
3 / 3
Merklingen, Germany
Member since 2011
Premium Member since 2026
Employees50 - 100
Certificates2
Turnover5 - 10 Mil.
Year of foundation1889
Marketing documents
Competencies
Technologies
Sheet Metal Processing
| Technologies | Lotsize | Length | Width | Height | Material thickness |
|---|---|---|---|---|---|
Laser cutting 2D | 1–10 M | 1–3,000 mm | 1–1,500 mm | — | 0.15–25 mm |
Bending / folding | 1–10 M | 5–4,550 mm | — | — | 0.2–15 mm |
Laser cutting, tube & section | 1–10 M | 0.5–3,000 mm | 1–150 mm | 1–150 mm | 1–10 mm |
Welding
| Technologies | Lotsize | Length | Width | Height | Weight | Material thickness |
|---|---|---|---|---|---|---|
Inert gas shielded arc welding (MIG/MAG) | 1–1 M | 1–3,000 mm | 1–3,000 mm | 1–3,000 mm | 0–1,000 kg | — |
Inert gas shielded arc welding (TIG) | 1–100 k | 1–3,000 mm | 1–3,000 mm | 1–3,000 mm | 0–1,000 kg | — |
Robot welding | 25–100 k | 10–7,000 mm | 10–4,000 mm | 10–2,000 mm | 0–1,500 kg | — |
Spot welding | 1–100 k | — | — | — | — | 1–3 mm |
Welded constructions / Structural Steelwork
| Technologies | Length | Width | Height | Weight |
|---|---|---|---|---|
Welded constructions (weldments) | 1–3,000 mm | 1–3,000 mm | 1–3,000 mm | 0–2,000 kg |
Machine frames / bases / racks | 1–2,000 mm | 1–2,000 mm | 1–2,000 mm | 0–1,000 kg |
Pipe & Tube Manufacturing
| Technologies | Lotsize | Length | Width | Height | Diameter | Material thickness |
|---|---|---|---|---|---|---|
Pipe bending | 1–10 M | 1–4,000 mm | — | — | 1–42 mm | 1–4 mm |
Laser cutting, tube & section | from 1 | from 1 mm | from 1 mm | from 1 mm | — | from 1 mm |
Assembly
| Technologies | Weight |
|---|---|
Mechanical assembly | 0–500 kg |
Turning
| Technologies | Lotsize | Length | Diameter |
|---|---|---|---|
Turning | 1–100 k | 5–1,000 mm | 5–110 mm |
Automatic turning (bar) | 0–100 k | 5–800 mm | 5–70 mm |
Assembly Group Manufacturing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Adhesive bonding | 1–10,000 | 1–3,000 mm | 1–3,000 mm | 1–1,500 mm | 1–300 mm | 0–500 kg | 1–10 mm |
Riveting | 1–10,000 | 1,000–1,001 mm | 1,000–1,001 mm | — | — | — | 1–4 mm |
Milling
| Technologies | Lotsize | Length | Width | Height |
|---|---|---|---|---|
Milling | 50–10,000 | 10–840 mm | 10–400 mm | 5–300 mm |
Drilling / Sawing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|---|
Sawing | 1–100 k | 10–6,000 mm | 5–500 mm | 5–500 mm | 3–500 mm | — |
Drilling / threading / tapping | 1–10,000 | 1–1,000 mm | 1–1,000 mm | 1–1,000 mm | — | 0–100 kg |
Materials
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steel
Light metals
Aluminium and aluminium alloys
Industries
Building, agricultural and forestry machinery manufacturingSpecial purpose machinery manufacturingAutomotive and vehicle constructionConstruction and architectural suppliesMechanical engineeringTelecommunication industryShipbuilding industryClean room technologyPaper and printing machinery industryFurniture industryMilitary engineeringMeasurement and control technique, laboratory equipmentMedical technologyAerospace and aviation industryBoiler, container and tank construction Air conditioning, refrigeration and ventilation industryInformation technology (hardware)Hydraulic and pneumatic industryHousehold appliance industryPrecision engineering, mechatronics and opticsPower generation and transmission industryElectrical industryChemical industryOffice machinery and suppliesMining and tunnel engineeringLighting industryAutomation and control engineeringFittings engineeringDrive and gear engineeringApparatus engineeringMachine tool manufacturingPlant engineering and constructionPackaging industry
Certificates
ISO 9001:2015
DIN EN ISO 3834
Parts & Machines
Machinery (3)
1 / 3
Technology
Laser cutting 2D
2 / 3
Drehautomat
ManufacturerMazak
Year of Construction2018
Technology
Automatic turning (bar)
3 / 3
3-Achs Fräsmaschine
ManufacturerDMG
Year of Construction2014
Technology
Milling
3 Machinery
Laser cutting 2D1
Automatic turning (bar)1
Milling1
Contact
Location
Main locationSalbergweg 15, Industriegebiet Breite, 89188 Merklingen, Germany
Further locations89188 Merklingen
