Dingler CNC- Technik GmbH & Co. KG
Germany, 72280 Dornstetten
Overview
About Dingler CNC- Technik GmbH & Co. KG
Who we are
A more than 35 years of experience as a supplier of machinery and vehicle parts gives us the opportunity to respond to your specific manufacturing spectrum. Our factory is equipped with advanced CNC 4-axis machining centers, lathes and milling centers, and an adequate CNC metrology. We produce precision milling and turning parts, including standard parts and problem parts, both in large and in small batches, with our focus on high-precision machining of cast iron, in particular transmission parts is. Products We manufacture turned parts with a diameter of 10 mm to 250 mm and lengths up to 500 mm, and milled parts up to 1100 mm edge length Materials Will handle virtually any steel, free cutting steel, stainless steel and non-ferrous metals such as copper, brass, aluminum, and cast iron, gray cast iron (GG) and spheroidal graphite cast iron (GGG) Processing methods Our modern machinery enables the complete machining of demanding and highly complex installation parts Program of delivery - U casta: motor housing, intermediate cover, cover plates, hubs, gear boxes, switch box, lead glasses, clamping rings, base, bearing caps, connecting rings, stand heads, machine holder, switch handles, flanges, stop rings, drive enclosure, adapter, iron plates - Made of steel and non-ferrous metals such as: pump wheel hub, change gear, bearing sleeve, ferrule, shaft sleeve, pinion shaft, spindle, thrust washer, guide pin, socket, displacement cone, pipe cap, stainless steel washers, angle lever, baking, vibrators, belt pulley, knotter frame Heat treatment processes and surface coating Our services are completed by the conventional heat treatment processes suchExample, case hardening, nitriding, nitro-carburizing, TUFFTRIDE QPQ, as well as the best known methods for surface coating, such as chrome plating galvanizing, burnishing, among others Certified Quality Qualified staff, structured processes and the use of modern technology in production and measurement technology, the building blocks for the highest quality standards to be met by our products and services are
1 / 1
Dornstetten, Germany
Member since 2001
Employees10 - 20
Certificates1
Turnover1 - 5 Mil.
Year of foundation1972
Competencies
Technologies
Turning
| Technologies | Lotsize | Length | Diameter |
|---|---|---|---|
Turning | 50–50,000 | 10–500 mm | 10–300 mm |
Automatic turning (bar) | 50–50,000 | 10–500 mm | 10–300 mm |
Measuring & Testing
| Technologies | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|
Measuring / testing | 10–1,200 mm | 10–850 mm | 10–800 mm | 5–800 mm | 0–1,000 kg |
Finishing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|---|
Circular honing - internal | 100–2,000 | 50–200 mm | 50–200 mm | 50–300 mm | 30–100 mm | 0–100 kg |
Precision honing | 100–2,000 | 50–200 mm | — | — | 30–100 mm | — |
Milling
| Technologies | Lotsize | Length | Width | Height | Weight |
|---|---|---|---|---|---|
Milling | 10–20,000 | 20–1,000 mm | 20–1,000 mm | 20–1,000 mm | — |
Form milling (3 D) | 10–20,000 | 20–1,000 mm | 20–1,000 mm | 20–1,000 mm | — |
HSC milling | 10–20,000 | 20–1,000 mm | 20–1,000 mm | 20–1,000 mm | 0–1,200 kg |
Drilling / Sawing
| Technologies | Lotsize | Length | Width | Height | Weight |
|---|---|---|---|---|---|
Drilling / threading / tapping | 10–20,000 | 20–1,000 mm | 20–1,000 mm | 20–1,000 mm | 0–1,200 kg |
Materials
Plastics/synthetic materials
ThermoplasticsThermosetsElastomersSilocone (LSR)Natural and vulcanised rubberGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materials
Natural materials
Wood/timberRock
Heavy metals
Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloysSolder
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel
Precious metals
SilverGoldPlatinumOther precious metals
Cast metals
Cast steelCast iron
Non-metal inorganic materials
CeramicsGlassConcreteCast mineralsGraphite
Advanced Materials
Nickel alloy (Inconel, Monel, Hastelloy)
Light metals
Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys
Sintered materials
Metal powder for formed partsMetal powder for hard metal
Industries
Machine tool manufacturingMeasurement and control technique, laboratory equipmentPower generation and transmission industryMining and tunnel engineeringHydraulic and pneumatic industryAutomotive and vehicle constructionBuilding, agricultural and forestry machinery manufacturingSpecial purpose machinery manufacturingPackaging industryMedical technologyPrecision engineering, mechatronics and opticsConstruction and architectural suppliesAerospace and aviation industryRailway and rail vehicles industryFurniture industryApparatus engineeringAutomation and control engineeringMechanical engineeringDrive and gear engineering
Certificates
ISO 9001:2015
Parts & Machines
Parts (1)
1 / 1
Drehteile
DescriptionWir fertigen Drehteile mit einem Durchmesser von 10mm bis 250 mm und Längen bis 500 mm, sowie Frästeile bis 1100 mm Kantenlänge
Machinery (11)
1 / 11
TX-1
ManufacturerTakisawa
Control-
Year of Construction1997
2 / 11
TX-1
ManufacturerTakisawa
Control-
Year of Construction1998
3 / 11
HG 630
ManufacturerMatsuura
ControlFanuc
Year of Construction2007
4 / 11
HG 630
ManufacturerMatsuura
ControlFanuc
Year of Construction2006
5 / 11
HG 630
ManufacturerHitachi
ControlFanuc
Year of Construction2001
6 / 11
Mam 600
ManufacturerMatsuura
ControlYasnac
Year of Construction2001
7 / 11
H 405
ManufacturerMatsuura
ControlFaunc
Year of Construction2007
8 / 11
CV-616
ManufacturerSunnen
Control-
Year of Construction2001
9 / 11
HG 630
ManufacturerMatsuura
ControlFanuc
Year of Construction2004
10 / 11
TC-3
ManufacturerTaikisawa
ControlFanuc
Year of Construction2001
11 / 11
PCM - 850
ManufacturerZeiss
ControlUnix
Year of Construction2007
1 Parts
11 Machinery
Contact
Location
Main locationLise-Meitner-Str. 10, 72280 Dornstetten, Germany
Further locations72280 Dornstetten
Bundesland: Baden-Württemberg
Regierungsbezirk: Karlsruhe
Landkreis: Freudenstadt
Bundesland: Baden-Württemberg
Regierungsbezirk: Karlsruhe
Landkreis: Freudenstadt
Company contact
Contact persons
JD
Joachim Dingler
