About Ingenieurbau Bismark GmbH
Who we are
Ingenieurbau Bismark (IBB) GmbH was founded in 1990 and is headquartered in 39629 Bismark. Ingenieurbau Bismark GmbH currently employs 38 people. The core area of the company is steel and plant engineering. The product profile covers the design, manufacture and assembly of complete steel buildings in system construction as well as special structures. Production takes place in a production hall with an area of 6,000 m². The core of modern production technology is a PCD 1100/1100 DG CNC drilling and sawing machine. This means that steel profiles up to a height of 1,100 mm and a length of 22 m can be processed automatically as far as possible. A computer-controlled NC drilling machine enables the automated production of flame parts from thick sheets up to 60 mm thick. For the production of industrial railings, ibb offers a modern CNC mandrel tube bending system with integrated rolling and ring bending equipment. 11 floor-controlled or radio-controlled bridge cranes enable effective handling of steel structures with a single piece weight of up to 15 t. A modern and powerful continuous blasting system with a throughput width of 1,500 mm and a newly built paint spray house with underfloor extraction with an area fund of 500 m² ensure the high-quality execution of paint coating work and anti-corrosion coatings. Since December 2000, the ibb has been certified in accordance with DIN EN ISO 9001:2000. Ingenieurbau Bismark GmbH has the manufacturer qualification for welding steel structures in accordance with DIN 18800-7:2002-09 for welding processes 111 Manual arc welding (E) 135 MAG welding (t MAG) 783 Ignition stud welding (DS) and has had the WPK certificate in accordance with DIN EN 1090-1 and the steel construction welding certificate DIN EN 1090-2/EXC3 since 2013. Ingenieurbau Bismark GmbH employs highly qualified and experienced architects and specialist engineers and is therefore able to plan complex construction projects and carry out qualified construction management.
1 / 1
Bismark (Altmark), Germany
Member since 2024
Employees20 - 50
Turnover1 - 5 Mil.
Competencies
Technologies
Welding
| Technologies | Lotsize | Length | Width | Height | Weight |
|---|---|---|---|---|---|
Inert gas shielded arc welding (MIG/MAG) | from 1 | from 0 mm | from 0 mm | from 0 mm | from 0 kg |
Stud welding | 1–1,000 | — | — | — | — |
Welded constructions / Structural Steelwork
| Technologies | Length | Width | Height | Weight |
|---|---|---|---|---|
Welded constructions (weldments) | from 0 mm | from 0 mm | from 0 mm | from 0 kg |
Pipe & Tube Manufacturing
| Technologies | Lotsize | Length | Diameter | Material thickness |
|---|---|---|---|---|
Pipe bending | 1–1,000 | from 0 mm | 0–50 mm | from 0 mm |
Sheet Metal Processing
| Technologies | Lotsize | Length | Width | Weight | Material thickness |
|---|---|---|---|---|---|
Bending / folding | 1–1,000 | 1,000–3,000 mm | — | — | 0–8 mm |
Plasma fusion cutting | 1–10 M | 140–6,000 mm | 210–2,500 mm | 0–3,840 kg | 4–40 mm |
Shearing (rectangular blank/strip) | 1–1,000 | — | — | — | 3–10 mm |
Drilling / Sawing
| Technologies | Lotsize | Length | Width | Height | Diameter |
|---|---|---|---|---|---|
Sawing | 1–10 M | 3,000–18,000 mm | 70–1,000 mm | 30–500 mm | 30–500 mm |
Surface Treatment
| Technologies | Lotsize | Length | Width | Height | Weight |
|---|---|---|---|---|---|
Sand blasting | 1–10 M | 60–18,000 mm | 20–1,500 mm | 5–400 mm | 0–9,000 kg |
Spray-painting | 1–10 M | 60–18,000 mm | 20–3,500 mm | 5–3,500 mm | 0–9,000 kg |
Materials
Light metals
Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys
Heavy metals
Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloysSolder
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel
Industries
Plant engineering and construction
Contact
Location
Main locationWartenberger Chaussee 4, 39629 Bismark (Altmark), Germany
