Innospan GmbH

Germany, 45968 Gladbeck

Overview

About Innospan GmbH

Who we are

With a clear view of the future, the company plans to expand its product range and enter new markets while maintaining the high standards of quality and precision that have characterized it since its inception. The machining company innospan is therefore not only an example of successful family tradition, but also a pioneer in the industry that is ready to take on the challenges of the future. innospan GmbH is your competent partner in the area of CNC turning technology and CNC milling technology. The wide range of services includes the production of individual parts (prototypes), small series and assembly assemblies made of e.g. stainless steel, steel, aluminum, copper alloys (brass) and plastic. The production, which is equipped with modern CNC machining centers, enables a high level of precision and flexibility in meeting your requirements.

Gladbeck, Germany

Member since 2025

Employees5 - 10

Certificates1

Turnover1 - 5 Mil.

Year of foundation1998

Marketing documents

ALLGEM~1.PDFPDF File

Competencies

Technologies

Turning

Technologies	Lotsize	Length	Diameter	Weight
Turning	1–2,000	3–1,000 mm	1–320 mm	—
Automatic turning (bar)	1–2,000	3–1,000 mm	1–320 mm	—
Swiss turning	1–2,000	3–1,500 mm	5–70 mm	—
Full-range turning (including milling)	1–2,000	3–1,000 mm	5–320 mm	—
Hard turning	1–2,000	3–1,000 mm	5–320 mm	—
Shaft machining	1–2,000	3–1,000 mm	5–320 mm	0–200 kg

Sheet Metal Processing

Technologies	Lotsize	Length	Width	Material thickness
Laser cutting 2D	from 1	from 0 mm	from 0 mm	from 0 mm
Bending / folding	from 1	from 0 mm	—	from 0 mm

Welding

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Inert gas shielded arc welding (MIG/MAG)	from 1	0–2,500 mm	0–2,500 mm	0–2,500 mm	—	0–500 kg	—
Inert gas shielded arc welding (TIG)	from 1	0–2,500 mm	0–2,500 mm	0–2,500 mm	—	from 0 kg	—
Manual electrode welding	1–2,000	1–2,500 mm	1–2,500 mm	1–2,500 mm	1–1,000 mm	0–500 kg	1–100 mm
Soldering	1–2,000	1–2,500 mm	1–2,500 mm	1–2,500 mm	1–100 mm	0–500 kg	—

Welded constructions / Structural Steelwork

Technologies	Length	Width	Height	Weight
Welded constructions (weldments)	0–2,500 mm	0–2,500 mm	0–2,500 mm	0–500 kg
Beam prefabrication	1–3,000 mm	1–820 mm	1–600 mm	0–2,500 kg

Machining (Plastics & Rubber)

Technologies	Lotsize	Length	Width	Height	Diameter
Turning	1–2,000	1–1,500 mm	—	—	1–320 mm
Automatic turning (bar)	1–2,000	1–1,500 mm	—	—	1–320 mm
Full-range turning (including milling)	1–1,000	from 0 mm	—	—	from 0 mm
Milling	1–2,000	1–3,000 mm	1–820 mm	1–600 mm	—
Form milling (3 D)	1–2,000	1–3,000 mm	1–820 mm	1–600 mm	—

Jigmaking

Technologies	Length	Width	Height	Weight
Drilling / milling jigs	1–3,000 mm	1–820 mm	1–600 mm	0–1,000 kg
Gauges	1–3,000 mm	1–820 mm	1–600 mm	0–1,000 kg
Measuring / testing jigs	1–3,000 mm	1–820 mm	1–600 mm	0–1,000 kg
Assembly jigs	1–3,000 mm	1–820 mm	1–600 mm	0–1,000 kg
Welding jigs	1–3,000 mm	1–820 mm	1–600 mm	0–1,000 kg
Clamping devices	1–3,000 mm	1–820 mm	1–600 mm	0–1,000 kg

Mechanical Engineering

Technologies	Lotsize	Length	Width	Height	Weight
Mechanical engineering	1–2,000	1–2,500 mm	1–2,500 mm	1–2,500 mm	0–1,000 kg
Hydraulic engineering	1–2,000	1–2,500 mm	1–2,500 mm	1–2,500 mm	0–1,000 kg
Pneumatic engineering	1–2,000	1–2,500 mm	1–2,500 mm	1–2,500 mm	0–1,000 kg
Apparatus engineering	1–2,000	1–2,500 mm	1–2,500 mm	1–2,500 mm	0–1,000 kg
Tool building	1–2,000	1–2,500 mm	1–2,500 mm	1–2,500 mm	0–1,000 kg
Handling technology	1–2,000	1–2,500 mm	1–2,500 mm	1–2,500 mm	0–1,000 kg

Gear Making

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Cylindrical gear / spur gear	from 1	from 0 mm	—	—	from 0 mm	—
Sprocket (wheel)	1–2,000	1–500 mm	—	—	1–320 mm	0–100 kg
Cogged belt pulley	1–2,000	1–500 mm	—	—	1–320 mm	0–100 kg
Rack (toothed)	1–2,000	1–3,000 mm	1–500 mm	1–500 mm	1–500 mm	0–1,000 kg

Finishing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
External cylindrical grinding	1–100	from 0 mm	—	—	from 0 mm	—
Surface grinding machine	1–40	1–6,000 mm	1–580 mm	1–265 mm	—	0–3,000 kg

Milling

Technologies	Lotsize	Length	Width	Height	Weight
Milling	1–2,000	1–3,000 mm	1–820 mm	1–650 mm	—
Form milling (3 D)	1–2,000	1–3,000 mm	1–820 mm	1–650 mm	—
HSC milling	1–2,000	1–3,000 mm	1–820 mm	1–650 mm	0–1,000 kg

Cutting dies / deep drawing dies

Technologies
Die replacement / wearing part manufacturing

Drilling / Sawing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Sawing	1–2,000	12–6,000 mm	0–400 mm	0–320 mm	0–320 mm	—
Drilling / threading / tapping	1–2,000	1–6,000 mm	1–820 mm	1–600 mm	—	0–1,000 kg

Materials

Light metals

Aluminium and aluminium alloysTitanium and titanium alloys

Plastics/synthetic materials

ThermoplasticsAcrylic (PMMA)High performance plasticThermosetsElastomersSilocone (LSR)Natural and vulcanised rubberGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materialsNatural Fibre Composites (NFC)

Steel

Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steel

Cast metals

Cast steelCast iron

Heavy metals

Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloys

Industries

Precision engineering, mechatronics and opticsBoiler, container and tank construction Automation and control engineeringAerospace and aviation industryFittings engineeringMechanical engineeringMedical technologySpecial purpose machinery manufacturingShipbuilding industryPlant engineering and constructionDrive and gear engineeringMachine tool manufacturingApparatus engineeringAutomotive and vehicle constructionLighting industryChemical industryRailway and rail vehicles industry

+9 moreShow less
