manroland sheetfed GmbH

Germany, 63075 Offenbach am Main

Overview

About manroland sheetfed GmbH

Who we are

Diene production services Precision and experience. manroland is the world's second-largest press manufacturer with about 900 employees. The printing presses lives of precision. You can profetieren it, for manroland has many years of expertise as a world leader not only in sophisticated printing machines: Our professionals bring their years of experience with a manufacturing services for you. Quality testing and certification. manroland is certified according to DIN EN ISO 9001:2000 and DIN EN ISO 14001:2005. Annual audits ensure the honing demands on the processes safely. With our machines almost every feature can be verifizeirt professional manner. In addition, our laboratories provide materials analysis and Schlissbilder. Own foundry. The foundry with integrated model for large parts in Offenbach with an annual volume of up to 17,000 tonnes of cast iron saves valuable time in the match between model-making, foundry and manufacturing.For shorter lead times and lower costs for our customers. Diverse range of parts. From the lever through gears in Meisterradqualität to extremely heavy side walls, with tolerances of a few microns, thanks to a modern machine park. Also the production of any workpieces from batch size one is in the fast group everyday. Rotary bulk of production Rollers and cylinders. manroland offers the complete process chain for machining of cylinders and rollers: Turning, milling and drilling into a voltage on modern CNC machining centers and final grinding. There are also successful partnerships for gavanische surface finishing. Non-circular grinding. The special features of the machinery for rolling and the cylinder with appropriate controls is also the non-circular machining of precisely defined contours no problem. Prismatic large-part manufacturing Bulk of production.manroland manufacture components with size 2.2 meters wide x 2.5 meters long x 2 meters in height and weighing up to 2 tons. In the doubles table operating a processing to eleven meters in length. Our machines operate with a capacity of up to 100 kilowatts. Tools with a diameter up to 315 mm cutting depths allow con about 15 to 20 millimeters compared Gussverzüge and cast tension, with high-precision manufacturing of drilling intervals. Flat part manufacturing. CNC machine tools allow the highly efficient production of cubic flat parts with a machining of up to five pages in one setting. The machine tools are mostly equipped with special Ganauigkeitspakete ensure the highest quality for large component dimensions. Prismatic workpieces geometry primarily by complete machining on special parts that meet any of aluminum are in high quality requirements for CE-safety-related parts.For this we use a moderene five-axis machining round. Complete production Complete machining. The device construction, the tool engineering and CNC programming are aligned short response time for changes and new parts. Complex cubic workpieces are manufactured in several setups in multi-range operating on different processing centers: Small series of cast blanks with complex hole pattern and high quality requirements (up to it5) are among the references (levers, rails, slats and gear housing). Turned parts. Rings, flanges and wheels of medium dimensions are produced, but also gear shafts or special Exzentergleitlager with tolerance ranges of up to seven microns, including modern external and internal cylindrical grinding techno...

Offenbach am Main, Germany

Member since 2007

Premium Member since 2025

Employees> 1000

Certificates1

Year of foundation1871

Competencies

Technologies

Measuring & Testing

Technologies	Length	Width	Height	Diameter	Weight
Measuring / testing	10–4,000 mm	10–3,000 mm	10–2,500 mm	10–1,000 mm	0–4,000 kg

Turning

Technologies	Lotsize	Length	Diameter	Weight
Turning	1–1,000	10–1,000 mm	10–800 mm	—
Shaft machining	10–1,000	200–4,500 mm	20–1,000 mm	0–3,800 kg

Gear Making

Technologies	Lotsize	Length	Diameter	Weight
Cylindrical gear / spur gear	5–500	10–500 mm	500–1,000 mm	—
Cogged belt pulley	5–500	150–630 mm	200–1,000 mm	0–670 kg

Finishing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
External cylindrical grinding	5–1,000	100–1,500 mm	—	—	50–250 mm	—
Internal cylindrical grinding	5–1,000	50–500 mm	—	—	50–800 mm	—
Surface grinding machine	5–1,000	10–2,000 mm	10–500 mm	10–250 mm	—	0–500 kg
Coordinate jig grinding	5–1,000	10–150 mm	10–250 mm	10–150 mm	—	0–50 kg
Non-circular / crankshaft grinding	5–1,000	500–2,000 mm	—	—	—	0–500 kg

Assembly

Technologies	Weight
Mechanical assembly	0–20,000 kg
Electromechanical assembly	0–2,000 kg
Industrial / On-site-assembly	0–20,000 kg

Heat Treatment

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Annealing	1–1,000	5–800 mm	5–800 mm	5–800 mm	5–800 mm	0–500 kg
Induction hardening	1–100 k	5–2,000 mm	5–250 mm	5–2,000 mm	5–300 mm	0–250 kg
Vacuum annealing	1–1,000	5–800 mm	5–800 mm	5–800 mm	5–800 mm	0–500 kg
