Marco Piraccini Metallbau
Germany, 51789 Lindlar
Overview
About Marco Piraccini Metallbau
1 / 2
2 / 2
Lindlar, Germany
Member since 2016
Employees< 5
Certificates1
Year of foundation2011
Competencies
Technologies
Welded constructions / Structural Steelwork
| Technologies | Length | Width | Height | Weight |
|---|---|---|---|---|
Welded constructions (weldments) | 5–6,000 mm | 5–6,000 mm | 5–3,000 mm | 0–2,500 kg |
Machine frames / bases / racks | 5–6,000 mm | 5–6,000 mm | 5–3,000 mm | 0–2,500 kg |
Turning
| Technologies | Lotsize | Length | Diameter |
|---|---|---|---|
Turning | 1–100 | 1–300 mm | 1–185 mm |
Sheet Metal Processing
| Technologies | Lotsize | Length | Width | Weight | Material thickness |
|---|---|---|---|---|---|
Laser cutting 2D | 1–10,000 | 15–2,980 mm | 15–1,500 mm | 0–500 kg | 0.5–20 mm |
Bending / folding | 1–1,000 | 10–3,000 mm | — | — | 0.4–6 mm |
Plate rolling / bending | 1–100 | — | 10–1,000 mm | — | 1–3 mm |
Shearing (rectangular blank/strip) | 1–1,000 | — | — | — | 1–6 mm |
Welding
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Inert gas shielded arc welding (MIG/MAG) | 1–10,000 | 2–6,000 mm | 10–2,000 mm | 1–500 mm | 15–500 mm | 0–2,000 kg | 2–51 mm |
Inert gas shielded arc welding (TIG) | 1–1,000 | 1–6,000 mm | 1–3,000 mm | 1–1,500 mm | 2–1,000 mm | 0–1,000 kg | 0.5–20 mm |
Spot welding | 1–1,000 | — | — | — | — | — | 0.5–4 mm |
Manual electrode welding | 1–100 | 3–2,000 mm | 3–3,000 mm | 3–3,000 mm | 15–500 mm | 0–1,000 kg | 3–50 mm |
Stud welding | 1–1,000 | — | — | — | — | — | — |
Milling
| Technologies | Lotsize | Length | Width | Height | Weight |
|---|---|---|---|---|---|
Milling | 1–100 | 1–1,000 mm | 1–400 mm | 1–350 mm | 0–300 kg |
Drilling / Sawing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|---|
Sawing | 1–100 | 5–6,000 mm | 5–150 mm | 5–150 mm | 5–150 mm | — |
Drilling / threading / tapping | 1–100 | 1–6,000 mm | 1–250 mm | 1–300 mm | — | 0–50 kg |
Surface Treatment
| Technologies | Lotsize | Length | Width | Height | Weight |
|---|---|---|---|---|---|
Powder coating | 1–10,000 | 1–3,000 mm | 50–2,000 mm | 1–2,000 mm | 0–1,000 kg |
Sand blasting | 1–100 | 10–5,000 mm | 30–900 mm | 30–1,000 mm | 0–2,500 kg |
Materials
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Spring steel
Light metals
Aluminium and aluminium alloys
Industries
Apparatus engineeringClean room technologyMechanical engineeringFurniture industryConstruction and architectural suppliesPlant engineering and constructionBuilding, agricultural and forestry machinery manufacturingElectrical industryPackaging industryTelecommunication industryOffice machinery and suppliesPaper and printing machinery industrySpecial purpose machinery manufacturingBoiler, container and tank construction Household appliance industryChemical industryMachine tool manufacturing
Certificates
DIN EN 1090
Contact
Location
Main locationBrunnenweg 10, 51789 Lindlar, Germany
Company contact
Contact persons
MP
Marco Piraccini
