METDRA Metall- und Drahtwarenfabrik GmbH
Germany, 71229 Leonberg
Overview
About METDRA Metall- und Drahtwarenfabrik GmbH
Who we are
Located in the Metrolpolregion Stuttgart, we develop and manufacture for decades a wide range of industrially manufactured products of wire, tube and sheet metal. You will receive individual and customized solutions. From the first conceptual step to delivery, we support with our expert staff. Bent wire parts and technical articles Since 1963, we present ourselves as a modern and competent manufacturer of high quality products made of wire The wire parts are manufactured exactly according to customer's drawings, also in combination with pipe and sheet metal. • Quick and inexpensive, we produce your parts from 2mm to 10mm diameter • made of steel (ST37) or stainless steel (1.4301) • on CNC 3D or 2D bending machines. Our decades of know-how in the wire processing, as well as our own tool and fixture supports fast batch production of your parts. For further processing of your parts, we offer a wide variety of surfaces: • plastic coated • galvanized / plated • Nickel-plated • electrolytically polished • blasted If you wish, our quality control checks, and documents your wire parts up to 100%. We will pack according to your requirements and deliver on time to the required delivery date. Send us your data in formats DXF, DWG or in other 3-D formats (eg SolidWorks, Solid Edge, Catia, Pro-E, etc.).
1 / 1
Leonberg, Germany
Member since 2003
Employees50 - 100
Certificates2
Turnover5 - 10 Mil.
Year of foundation1963
Competencies
Technologies
Wire & Spring Bending
| Technologies | Lotsize | Diameter |
|---|---|---|
Wire bending | 50–10,000 | 2.5–10 mm |
Welded constructions / Structural Steelwork
| Technologies | Length | Width | Height | Weight |
|---|---|---|---|---|
Welded constructions (weldments) | 20–2,000 mm | 20–2,000 mm | 20–2,000 mm | 0–30 kg |
Pipe & Tube Manufacturing
| Technologies | Lotsize | Length | Diameter | Material thickness |
|---|---|---|---|---|
Pipe bending | 10–1,000 | 100–4,000 mm | 20–45 mm | 0–10 mm |
Welding
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Inert gas shielded arc welding (MIG/MAG) | 10–10,000 | 10–2,000 mm | 10–2,000 mm | 10–2,000 mm | — | 0–30 kg | — |
Inert gas shielded arc welding (TIG) | 10–10,000 | 10–2,000 mm | 10–2,000 mm | 10–2,000 mm | 2.5–45 mm | 0–30 kg | 2.5–45 mm |
Robot welding | 50–10,000 | 20–2,000 mm | 20–2,000 mm | 20–2,000 mm | — | 0–30 kg | — |
Spot welding | 1–10,000 | — | — | — | — | — | 1–5 mm |
Projection welding | 10–50,000 | — | — | — | — | — | 2.5–40 mm |
Sheet Metal Processing
| Technologies | Lotsize | Length | Material thickness |
|---|---|---|---|
Bending / folding | 1–10,000 | 10–2,000 mm | 1–10 mm |
Drilling / Sawing
| Technologies | Lotsize | Length | Width | Height | Weight |
|---|---|---|---|---|---|
Drilling / threading / tapping | 50–10,000 | 10–2,000 mm | 10–1,000 mm | 10–500 mm | 0–20 kg |
Surface Treatment
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Powder coating | 1–1,000 | 1–2,000 mm | 1–700 mm | 1–1,700 mm | — | 0–50 kg | — |
Galvanizing | 1–1,000 | 1–2,000 mm | 1–700 mm | 1–1,700 mm | 1–200 mm | 0–50 kg | 1–10 mm |
Materials
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steel
Plastics/synthetic materials
ThermoplasticsThermosetsElastomers
Light metals
Aluminium and aluminium alloys
Heavy metals
Copper-zinc alloys (brass)Copper and copper alloys
Industries
Apparatus engineeringAir conditioning, refrigeration and ventilation industryMachine tool manufacturingMilitary engineeringBoiler, container and tank construction Special purpose machinery manufacturingClean room technologyConstruction and architectural suppliesTelecommunication industryFurniture industryRailway and rail vehicles industryLighting industryFittings engineeringAerospace and aviation industryPower generation and transmission industryMining and tunnel engineeringShipbuilding industryPaper and printing machinery industryMeasurement and control technique, laboratory equipmentMedical technologyPrecision engineering, mechatronics and opticsElectrical industryBuilding, agricultural and forestry machinery manufacturingDrive and gear engineeringOffice machinery and suppliesHydraulic and pneumatic industryPackaging industryHousehold appliance industryChemical industryAutomotive and vehicle constructionPlant engineering and constructionAutomation and control engineeringInformation technology (hardware)Mechanical engineering
Certificates
ISO 9001:2015
ISO 9001:2008
Contact
Location
Main locationDieselstraße 9, 71229 Leonberg, Germany
Further locations71229 Leonberg
