About pbt-Konstruktionen <br>Claus Wanke
Who we are
We are specialized for the tool construction of depth tools within the range packaging machines. In addition count beside format tools also stamping machines, perforations and feeding of tablets. By the CNC Fertigungskapazität we manufacture in the meantime also milled pieces. The materials which can be worked on are aluminum, steel, V2A, as well as thermal and thermosetting polymers. The lot sizes are enough from 1 to 5000 pieces or more highly.
1 / 1
Murr, Germany
Member since 2008
Employees< 5
Certificates1
Turnover< 1 Mil.
Year of foundation2002
Competencies
Technologies
Cutting dies / deep drawing dies
| Technologies | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|
Punching / Cutting tools | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Follow-on composite tools | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Fineblanking tools | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Deep-drawing dies | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Die replacement / wearing part manufacturing | from 0 mm | from 0 mm | from 0 mm | from 0 mm | from 0 kg | from 0 mm |
Embossing / swage dies | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Milling
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Milling | 1–5,000 | 10–400 mm | 10–300 mm | 10–150 mm | from 0 mm | 0–50 kg | from 0 mm |
Form milling (3 D) | 1–5,000 | 10–400 mm | 10–300 mm | 10–150 mm | from 0 mm | 0–50 kg | from 0 mm |
Mould construction
| Technologies | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|
Squeeze moulds | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Drilling / Sawing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Drilling / threading / tapping | 1–5,000 | 10–400 mm | 10–300 mm | 10–150 mm | from 0 mm | 0–50 kg | from 0 mm |
Materials
Light metals
Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel
Plastics/synthetic materials
ThermoplasticsThermosetsElastomersSilocone (LSR)Natural and vulcanised rubberGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materialsWood-Plastic-Composites (WPC)Natural Fibre Composites (NFC)
Natural materials
Wood/timberRock
Advanced Materials
Nickel alloy (Inconel, Monel, Hastelloy)CarbideSilicium
Heavy metals
Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloysSolder
Cast metals
Cast steelCast iron
Non-metal inorganic materials
CeramicsGlassConcreteCast mineralsGraphite
Precious metals
SilverGoldPlatinumOther precious metals
Sintered materials
Metal powder for formed partsMetal powder for hard metal
Industries
Apparatus engineeringHydraulic and pneumatic industryPaper and printing machinery industryRailway and rail vehicles industryFittings engineeringMedical technologyFurniture industryMachine tool manufacturingAerospace and aviation industryAutomation and control engineeringDrive and gear engineeringPlant engineering and constructionMining and tunnel engineeringAutomotive and vehicle constructionConstruction and architectural suppliesOffice machinery and suppliesHousehold appliance industryAir conditioning, refrigeration and ventilation industryPrecision engineering, mechatronics and opticsElectrical industryMilitary engineeringBuilding, agricultural and forestry machinery manufacturingPower generation and transmission industrySpecial purpose machinery manufacturingPackaging industryMechanical engineeringMeasurement and control technique, laboratory equipmentBoiler, container and tank construction Chemical industryLighting industryInformation technology (hardware)Clean room technologyShipbuilding industryTelecommunication industry
Certificates
No certificates
Parts & Machines
Machinery (1)
1 / 1
VMC 300
ManufacturerEMCO
Control-
Year of Construction1998
Technology
MillingForm milling (3 D)Drilling / threading / tapping
1 Machinery
Milling1
Form milling (3 D)1
Drilling / threading / tapping1
Contact
Location
Main locationFrauenstr. 8, 71711 Murr, Germany
Further locations71711 Murr - Baden-Württemberg (BW) - Stuttgart - Ludwigsburg
Company contact
Contact persons
CW
Claus Wanke
