About SBF Fertigungstechnik GmbH & Co. KG
Who we are
Dear Ladies and Gentlemen, the SBF would be like to introduce as a supplier in your home. Our company is a supplier of workpieces, which are produced by Cutting production. Due to our flexible production and employed there highly skilled employees, we are able to single and serial parts and assemblies to produce timely and economically. Delivery program: Piston bushings bushings washers rings valve seats screws cone spool pipes sleeve shaft axis hub plug valve spring retainer pin roller bolt nozzle mandrels aperture spindles mandrel sleeve cover assembly Bock valve plate table threaded plate connecting pin torque arm gear sandpit spacer door shaft clamping tube pump housing gear holder electrode 3D shape mold cap switch shaft piston Rollenflanschplatte flange Supporting tube roller bearing sliding bush buoy float design light We will gladly process your rush order! We are certified according to DIN ISO 9001 and 14001. Machine list - The following machines are available: Milling machines: Heidenhain TNC 426 Travel: X1000 Y600 Z500 Tool changer 40 - Trade SK40 drive power 23 KW n = 8000U/min spindle cooling Table load up to 1000Kg Heidenhain iTNC530 Travel: X1000 Y600 Z700 4.Ache by CNC dividing head Tool changer 40 - Trade SK40 drive power 17 KW n = 8000U/min spindle cooling Direct measuring system on all machine axes Tool and Werkstückvermesssystem M & H Table load up to 1000Kg Machines turning: Control: Mazatrol Matrix Travel: X460, Z550, Y 110, C axis Programmable Tailstock, parts catcher and bar puller, feed and chuck, Driven Tools radially and axially Drive power 23 KW n = 4500U/min Lathe conventional D = 460, Z = 1500 Other: Heska Saw 260 b
1 / 1
Schwebheim, Germany
Member since 2009
Employees5 - 10
Certificates1
Turnover< 1 Mil.
Year of foundation2007
Marketing documents
Competencies
Technologies
Assembly
| Technologies | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|
Mechanical assembly | from 0 mm | from 0 mm | from 0 mm | from 0 mm | 0–3,200 kg | from 0 mm |
Electromechanical assembly | from 0 mm | from 0 mm | from 0 mm | from 0 mm | 0–750 kg | from 0 mm |
Industrial / On-site-assembly | from 0 mm | from 0 mm | from 0 mm | from 0 mm | 0–3,200 kg | from 0 mm |
Mould construction
| Technologies | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|
Injection moulds | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Pressure die cast molds | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Modelmaking | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Vacuum deep-drawing moulds | 10–2,500 mm | 10–1,500 mm | 10–1,500 mm | from 0 mm | 0–750 kg | from 0 mm |
Jigmaking
| Technologies | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|
Drilling / milling jigs | 10–600 mm | 10–1,000 mm | 10–600 mm | from 0 mm | 0–1,000 kg | from 0 mm |
Measuring / testing jigs | 10–600 mm | 10–1,000 mm | 10–600 mm | from 0 mm | 0–1,000 kg | from 0 mm |
Assembly jigs | 10–600 mm | 10–1,000 mm | 10–600 mm | from 0 mm | 0–1,000 kg | from 0 mm |
Welding jigs | 10–600 mm | 10–1,000 mm | 10–600 mm | from 0 mm | 0–1,000 kg | from 0 mm |
Clamping devices | 10–600 mm | 10–1,000 mm | 10–600 mm | from 0 mm | 0–1,000 kg | from 0 mm |
Turning
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Turning | 1–50,000 | 1–1,500 mm | from 0 mm | from 0 mm | 1–460 mm | from 0 kg | from 0 mm |
Automatic turning (bar) | 1–50,000 | 5–400 mm | from 0 mm | from 0 mm | 5–250 mm | from 0 kg | from 0 mm |
Assembly Group Manufacturing
| Technologies |
|---|
Adhesive bonding |
Riveting |
Milling
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Milling | 1–5,000 | 1–1,000 mm | 1–1,000 mm | 1–700 mm | from 0 mm | 0–1,000 kg | from 0 mm |
Form milling (3 D) | 1–5,000 | 1–1,000 mm | 1–1,000 mm | 1–700 mm | from 0 mm | 0–1,000 kg | from 0 mm |
HSC milling | 1–5,000 | 1–1,000 mm | 1–1,000 mm | 1–700 mm | from 0 mm | 0–1,000 kg | from 0 mm |
Drilling / Sawing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Sawing | 1–1,000 | 10–3,000 mm | 1–260 mm | 1–260 mm | 1–260 mm | from 0 kg | from 0 mm |
Drilling / threading / tapping | 1–5,000 | 1–1,000 mm | 1–1,000 mm | 1–700 mm | from 0 mm | 0–1,000 kg | from 0 mm |
Materials
Advanced Materials
Nickel alloy (Inconel, Monel, Hastelloy)CarbideSilicium
Non-metal inorganic materials
CeramicsGlassConcreteCast mineralsGraphite
Plastics/synthetic materials
ThermoplasticsThermosetsElastomersSilocone (LSR)Natural and vulcanised rubberGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materialsWood-Plastic-Composites (WPC)Natural Fibre Composites (NFC)
Cast metals
Cast steelCast iron
Heavy metals
Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloysSolder
Natural materials
Wood/timberRock
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel
Sintered materials
Metal powder for formed partsMetal powder for hard metal
Light metals
Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys
Precious metals
SilverGoldPlatinumOther precious metals
Industries
Telecommunication industryPower generation and transmission industryBuilding, agricultural and forestry machinery manufacturingChemical industryRailway and rail vehicles industryMedical technologyMechanical engineeringPackaging industryPlant engineering and constructionClean room technologyAutomation and control engineeringConstruction and architectural suppliesLighting industryApparatus engineeringMachine tool manufacturingFurniture industryMilitary engineeringMeasurement and control technique, laboratory equipmentOffice machinery and suppliesAir conditioning, refrigeration and ventilation industryPaper and printing machinery industryElectrical industryPrecision engineering, mechatronics and opticsHousehold appliance industryAutomotive and vehicle constructionFittings engineeringSpecial purpose machinery manufacturingDrive and gear engineeringHydraulic and pneumatic industryInformation technology (hardware)
Certificates
ISO 14001
Parts & Machines
Parts (2)
1 / 2
2 / 2
Machinery (5)
1 / 5
260
ManufacturerHESKA
Control-
Year of Construction1990
Technology
Sawing
2 / 5
SQT250IIMY
ManufacturerMazak
ControlMazatrol Matrix
Year of Construction2008
Technology
Turning
3 / 5
SQT250IIMY
ManufacturerMazak
ControlMATRIX
Year of Construction2008
Technology
Turning
4 / 5
TV1000A
ManufacturerSaeilo
Control-
Year of Construction2004
Technology
Drilling / threading / tappingForm milling (3 D)MillingHSC milling
5 / 5
TV 1000
ManufacturerSaeilo
Control-
Year of Construction1998
Technology
MillingDrilling / threading / tappingHSC millingForm milling (3 D)
2 Parts
5 Machinery
Sawing1
Turning2
Drilling / threading / tapping2
Form milling (3 D)2
Milling2
HSC milling2
Contact
Location
Main locationGulbransonstraße 13, 97525 Schwebheim, Germany
Further locationsBollog Fertigungstechnik
Gulbransson Str. 13
97525 Schwebheim
Bayern
Unterfranken
Schweinfurt
Gulbransson Str. 13
97525 Schwebheim
Bayern
Unterfranken
Schweinfurt
