About Schuler Präzisionstechnik KG
Who we are
Over 300 employees, a plant that is designed according to the latest knowledge of process control and material flow, as well as an exceptionally high level of vertical integration in line with well-trained employees ensure that the sum of skills and reliability applies at every point in the process chain. Our high-precision parts serve well-known customers from the following industries: automotive, mobile hydraulics, electrical drives, mechanical engineering, sensors, medical technology
1 / 6
2 / 6
3 / 6
4 / 6
5 / 6
6 / 6
Gosheim, Germany
Member since 2003
Employees200 - 500
Certificates5
Turnover20 - 50 Mil.
Year of foundation1925
Marketing documents
Competencies
Technologies
Turning
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Turning | 100–10 M | 1–1,000 mm | from 0 mm | from 0 mm | 3–65 mm | 0–5 kg | from 0 mm |
Automatic turning (bar) | 100–10 M | 0.5–500 mm | — | — | 3–65 mm | — | — |
Swiss turning | 100–100,000 | 0.5–320 mm | from 0 mm | from 0 mm | 3–32 mm | from 0 kg | from 0 mm |
Full-range turning (including milling) | 100–100,000 | 1–1,000 mm | from 0 mm | from 0 mm | 3–65 mm | from 0 kg | from 0 mm |
Hard turning | 1,000–100,000 | 5–200 mm | — | — | 5–90 mm | — | — |
Broaching | 500–3 M | 2–300 mm | — | — | 2–65 mm | — | — |
Deep-hole drilling | 500–3 M | 2–300 mm | 2–65 mm | 2–65 mm | 2–65 mm | 0–0.5 kg | — |
Centering / end facing | 500–3 M | 2–300 mm | — | — | 2–65 mm | — | — |
Shaft machining | 500–3 M | 2–300 mm | — | — | 2–65 mm | 0–0.5 kg | — |
Assembly
| Technologies | Weight |
|---|---|
Mechanical assembly | 0–0.5 kg |
Gear Making
| Technologies | Lotsize | Length | Diameter | Weight |
|---|---|---|---|---|
Cylindrical gear / spur gear | 500–3 M | 4–300 mm | 2–65 mm | — |
Worm gear | 500–3 M | 4–300 mm | 2–65 mm | 0–0.5 kg |
Finishing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|---|
External cylindrical grinding | 500–100,000 | 5–300 mm | — | — | 2–65 mm | — |
Centreless grinding | 500–100,000 | 5–300 mm | — | — | 2–65 mm | 0–0.5 kg |
Profile grinding | 500–100,000 | 5–200 mm | 5–65 mm | 5–65 mm | 2–65 mm | — |
Rotofinishing, barrel finishing | 500–100,000 | 5–100 mm | 5–65 mm | 5–65 mm | — | — |
Non-circular / crankshaft grinding | 500–100,000 | 5–300 mm | — | — | — | 0–0.5 kg |
Threading
| Technologies | Lotsize | Length | Diameter | Weight |
|---|---|---|---|---|
Thread rolling | 500–100,000 | 5–300 mm | 2–65 mm | — |
Thread whirling | 500–3 M | 5–300 mm | 2–65 mm | 0–0.5 kg |
Worm milling | 500–100,000 | 2–300 mm | 2–65 mm | 0–0.5 kg |
Worm rolling | 500–3 M | 5–100 mm | 2–65 mm | — |
Assembly Group Manufacturing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Adhesive bonding | 500–50 M | 4–300 mm | 4–100 mm | 4–300 mm | 4–65 mm | 0–0.5 kg | 4–100 mm |
Riveting | 500–500,000 | 4–300 mm | 4–100 mm | — | — | — | 4–100 mm |
Shrinking / cold-stretching | 500–500,000 | 4–300 mm | — | — | 4–100 mm | 0–0.5 kg | — |
Milling
| Technologies | Lotsize | Length | Width | Height | Diameter |
|---|---|---|---|---|---|
Milling | 500–100,000 | 10–300 mm | 10–300 mm | 10–300 mm | — |
5-axis milling machines | 500–100,000 | 10–300 mm | 10–300 mm | 10–300 mm | — |
Full-range milling (including turning) | 500–100,000 | 10–300 mm | 10–65 mm | 10–300 mm | 10–65 mm |
Labelling / marking
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|---|
Engraver milling | 500–100,000 | 10–300 mm | 10–65 mm | 10–65 mm | 2–65 mm | 0–0.5 kg |
Laser marking / Laser inscription | 500–1 M | 5–300 mm | 5–65 mm | 5–65 mm | 2–65 mm | — |
Drilling / Sawing
| Technologies | Lotsize | Length | Width | Height | Weight |
|---|---|---|---|---|---|
Drilling / threading / tapping | 500–100,000 | 10–300 mm | 10–65 mm | 10–300 mm | 0–0.5 kg |
Materials
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel
Light metals
Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys
Advanced Materials
Nickel alloy (Inconel, Monel, Hastelloy)
Heavy metals
Copper and copper alloysZinc and zinc alloysSolder
Plastics/synthetic materials
High performance plastic
Industries
Precision engineering, mechatronics and opticsHydraulic and pneumatic industryAir conditioning, refrigeration and ventilation industryMeasurement and control technique, laboratory equipmentDrive and gear engineeringMechanical engineeringElectrical industryAerospace and aviation industryAutomotive and vehicle constructionMedical technology
Certificates
ISO 9001:2015
ISO 9001:2008
ISO 14001
IATF 16949:2016
EN ISO 13485
Parts & Machines
Parts (1)
1 / 1
1 Parts
