Werkzeugbau Langkamm GmbH

Germany, 63694 Limeshain

Overview

About Werkzeugbau Langkamm GmbH

Who we are

Our services at a glance high-precision mechanical processing of steel, non-ferrous materials, aluminum and plastics mountable complete manufacturing / assembly of components Clamping tools, machine spindles, dowels, bushings, gauges, screws, etc. Sonderzentrierspitzen: to MC6 in hardened version or with carbide insert Grinding machine spindles (all versions KK, MK, SK, etc.) Cylindrical grinding in wage labor Polishing grinding Repair of machine parts by hard chrome plating or welding Work to model Measuring method: 3D coordinate measuring machine, digital height gauge, hardness tester, surface testing Data: Transfer your data in DXF, DWG, IGES, etc. .. And in cooperation with reliable partners: Production including tempering, nitriding, deep hole drilling, gear cutting, and much more.

1 / 2

2 / 2

Limeshain, Germany

Member since 2006

Employees20 - 50

Certificates1

Turnover1 - 5 Mil.

Year of foundation1995

Marketing documents

DIN EN ISO 9001:2000 Maschinenliste

Competencies

Technologies

Measuring & Testing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Measuring / testing	1–1,000	1–500 mm	1–400 mm	1–400 mm	1–400 mm	0–250 kg	from 0 mm

Assembly

Technologies	Length	Width	Height	Diameter	Weight	Material thickness
Mechanical assembly	from 0 mm	from 0 mm	from 0 mm	from 0 mm	0–150 kg	from 0 mm
Industrial / On-site-assembly	from 0 mm	from 0 mm	from 0 mm	from 0 mm	0–250 kg	from 0 mm

Cutting dies / deep drawing dies

Technologies	Length	Width	Height	Diameter	Weight	Material thickness
Punching / Cutting tools	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm
Follow-on composite tools	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm
Fineblanking tools	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm
Deep-drawing dies	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm
Trimming	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm
Die replacement / wearing part manufacturing	from 0 mm	from 0 mm	from 0 mm	from 0 mm	from 0 kg	from 0 mm
Embossing / swage dies	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm

Finishing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
External cylindrical grinding	1–1,000	10–1,500 mm	—	—	10–500 mm	0–300 kg	—
Internal cylindrical grinding	1–1,000	10–1,000 mm	from 0 mm	from 0 mm	10–500 mm	from 0 kg	from 0 mm
Surface grinding machine	1–1,000	1–650 mm	1–500 mm	1–400 mm	from 0 mm	0–150 kg	from 0 mm

Turning

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Turning	1–400	5–2,000 mm	from 0 mm	from 0 mm	5–830 mm	0–500 kg	from 0 mm
Full-range turning (including milling)	20–1,000	5–300 mm	—	—	50–300 mm	—	—

Jigmaking

Technologies	Length	Width	Height	Diameter	Weight	Material thickness
Gauges	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm
Measuring / testing jigs	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm
Assembly jigs	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm
Clamping devices	10–2,500 mm	10–1,500 mm	10–1,500 mm	from 0 mm	0–1,500 kg	from 0 mm

Threading

Technologies	Lotsize	Length	Diameter	Weight
Thread grinding	5–500	50–1,500 mm	10–350 mm	0–300 kg

Drilling / Sawing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Drilling / threading / tapping	1–500	10–1,250 mm	10–880 mm	10–800 mm	from 0 mm	0–1,000 kg	from 0 mm

Materials

Natural materials

Wood/timberRock

Sintered materials

Metal powder for formed partsMetal powder for hard metal

Cast metals

Cast steelCast iron

Precious metals

SilverGoldPlatinumOther precious metals

Advanced Materials

Nickel alloy (Inconel, Monel, Hastelloy)CarbideSilicium

Light metals

Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys

Heavy metals

Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloysSolder

Steel

Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel

Non-metal inorganic materials

CeramicsGlassConcreteCast mineralsGraphite

Plastics/synthetic materials

ThermoplasticsThermosetsElastomersSilocone (LSR)Natural and vulcanised rubberGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materialsWood-Plastic-Composites (WPC)Natural Fibre Composites (NFC)

Industries

Power generation and transmission industryApparatus engineeringRailway and rail vehicles industryLighting industryTelecommunication industryClean room technologyMechanical engineeringConstruction and architectural suppliesDrive and gear engineeringInformation technology (hardware)Household appliance industryShipbuilding industryFittings engineeringElectrical industryHydraulic and pneumatic industryPaper and printing machinery industryAutomotive and vehicle constructionPackaging industryPlant engineering and constructionAir conditioning, refrigeration and ventilation industryFurniture industryMachine tool manufacturingMedical technologyMeasurement and control technique, laboratory equipmentMining and tunnel engineeringAerospace and aviation industryOffice machinery and suppliesAutomation and control engineeringChemical industryPrecision engineering, mechatronics and opticsBoiler, container and tank construction Military engineeringSpecial purpose machinery manufacturingBuilding, agricultural and forestry machinery manufacturing

+26 moreShow less

Certificates

ISO 9001:2015

Contact

Location

Main locationHeegwaldring 21, 63694 Limeshain, Germany

This map is hosted on Google Maps. See
privacy policy.

Further locations63694 Limeshain
Bundesland: Hessen
Regierungsbezirk: Darmstadt
Landkreis: Wetteraukreis

Company contact

Contact persons

Jochen Langkamm
