Overview
About WMV-Solution GmbH
Who we are
We are a specialized manufacturing company with a focus on precise individual parts in the field of tool, machine and fixture construction, manufactured on modern 3 and 5-axis milling machines, CNC turning centers and by wire and sink EDM. In addition, we offer surface and cylindrical grinding, component assembly including functional testing and the organization of proven third-party services such as hardening or burnishing — all from a single source. Our production is based on digital processes: Whether samples or series parts based on CAD data — we take over your data sets and process them directly via our CAM software. Thanks to automated loading systems from BMO, we guarantee economical and reliable production — even with complex requirements.
1 / 1
Weilmünster, Germany
Member since 2025
Premium Member since 2025
Employees10 - 20
Certificates1
Turnover1 - 5 Mil.
Marketing documents
Competencies
Technologies
Turning
| Technologies | Lotsize | Length | Diameter |
|---|---|---|---|
Turning | 100–1,000 | 100–1,000 mm | 50–200 mm |
Full-range turning (including milling) | 0–10,000 | 0–400 mm | 0–200 mm |
Machining (Plastics & Rubber)
Mould construction
| Technologies | Length | Width | Height | Weight |
|---|---|---|---|---|
Injection moulds | 0–500 mm | 0–500 mm | 0–200 mm | 0–80 kg |
Pressure die cast molds | 0–500 mm | 0–500 mm | 0–200 mm | 0–80 kg |
Modelmaking | 0–500 mm | 0–500 mm | 0–200 mm | 0–80 kg |
Squeeze moulds | 0–500 mm | 0–500 mm | 0–200 mm | 0–80 kg |
Vacuum deep-drawing moulds | 0–500 mm | 0–500 mm | 0–200 mm | 0–80 kg |
Jigmaking
| Technologies | Length | Width | Height | Weight |
|---|---|---|---|---|
Drilling / milling jigs | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Gauges | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Measuring / testing jigs | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Assembly jigs | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Welding jigs | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Clamping devices | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Mechanical Engineering
| Technologies | Lotsize | Length | Width | Height | Weight |
|---|---|---|---|---|---|
Mechanical engineering | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Hydraulic engineering | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Pneumatic engineering | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Apparatus engineering | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Tool building | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Handling technology | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–80 kg |
Assembly
| Technologies | Weight |
|---|---|
Mechanical assembly | 0–80 kg |
Industrial / On-site-assembly | 0–80 kg |
Measuring & Testing
| Technologies | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|
Measuring / testing | 0–500 mm | 0–500 mm | 0–200 mm | 0–200 mm | 0–50 kg |
Surface Treatment
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Anodizing | 0–500 | 0–600 mm | 0–600 mm | 0–250 mm | — | 0–50 kg | — |
Blacking | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | — | 0–80 kg | — |
CVD-coating | 0–500 | 0–600 mm | 0–600 mm | 0–250 mm | 0–250 mm | 0–80 kg | 0–5 mm |
Electroplating | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | — | 0–80 kg | — |
Plasma coating | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–250 mm | 0–80 kg | — |
Galvanizing | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–250 mm | 0–80 kg | 0–5 mm |
Finishing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|---|
External cylindrical grinding | 10–100 | 100–1,000 mm | — | — | 50–200 mm | — |
Circular honing - internal | 0–100 | 0–200 mm | 0–150 mm | 0–150 mm | 0–50 mm | 0–25 kg |
Surface grinding machine | 0–1,000 | 0–400 mm | 0–350 mm | 0–60 mm | — | 0–25 kg |
Heat Treatment
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|---|
Case hardening/surface hardening | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–250 mm | 0–80 kg |
Hardening | 0–6,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–250 mm | 0–80 kg |
Nitriding processes | 0–25,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–250 mm | 0–80 kg |
Vacuum annealing | 0–5,000 | 0–600 mm | 0–600 mm | 0–250 mm | 0–250 mm | 0–80 kg |
Assembly Group Manufacturing
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight | Material thickness |
|---|---|---|---|---|---|---|---|
Adhesive bonding | 0–500 | 0–600 mm | 0–600 mm | 0–250 mm | 0–50 mm | 0–50 kg | 0–5 mm |
Milling
| Technologies | Lotsize | Length | Width | Height | Diameter | Weight |
|---|---|---|---|---|---|---|
Milling | 1–1,000 | 1–3,000 mm | 1–1,000 mm | 1–500 mm | — | — |
5-axis milling machines | 0–1,000 | 1–3,000 mm | 1–1,000 mm | 1–550 mm | — | — |
Form milling (3 D) | 1–1,000 | 1–3,000 mm | 1–1,000 mm | 1–300 mm | — | — |
Full-range milling (including turning) | 0–10,000 | 0–500 mm | 0–500 mm | 0–200 mm | 0–200 mm | — |
HSC milling | 0–10,000 | 0–500 mm | 0–200 mm | 0–200 mm | — | 0–50 kg |
Drilling / Sawing
| Technologies | Lotsize | Length | Width | Height | Diameter |
|---|---|---|---|---|---|
Sawing | 0–5,000 | 0–1,000 mm | 0–250 mm | 0–250 mm | 0–250 mm |
Materials
Plastics/synthetic materials
ThermoplasticsAcrylic (PMMA)High performance plasticThermosetsElastomersSilocone (LSR)Natural and vulcanised rubberGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materialsWood-Plastic-Composites (WPC)Natural Fibre Composites (NFC)
Light metals
Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys
Heavy metals
Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloysSolder
Cast metals
Cast steelCast iron
Steel
Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel
Industries
Building, agricultural and forestry machinery manufacturingPrecision engineering, mechatronics and opticsHydraulic and pneumatic industryAerospace and aviation industrySpecial purpose machinery manufacturingMachine tool manufacturingPackaging industryPaper and printing machinery industryPlant engineering and constructionDrive and gear engineeringApparatus engineeringAutomation and control engineeringAutomotive and vehicle constructionRailway and rail vehicles industryMechanical engineeringMilitary engineering
Certificates
No certificates
Parts & Machines
Parts (4)
1 / 4
Freiform
Technology5-axis milling machines
MaterialAluminium and aluminium alloys
Dimensions
Width400 mm
Height400 mm
Length30 mm
ComplexityMedium
IndustriesMechanical engineering
2 / 4
Formbauteil
Technology5-axis milling machines
MaterialTool steel
Dimensions
Width300 mm
Height200 mm
Length120 mm
ComplexityHigh
3 / 4
Trennmesser
TechnologyMilling
MaterialTool steel
Dimensions
Length8 mm
Height10 mm
Width30 mm
ComplexityHigh
4 / 4
Führungshülsen
TechnologyFull-range milling (including turning)
MaterialTool steel
Dimensions
Length150 mm
Height30 mm
Width30 mm
Diameter30 mm
Machinery (1)
1 / 1
Acura 65
ManufacturerHedelius
ControlHeidenhain
Year of Construction2024
Technology
5-axis milling machines
4 Parts
5-axis milling machines2
Milling1
Full-range milling (including turning)1
1 Machinery
5-axis milling machines1
Contact
Location
Main locationIserbachstraße 11a, 35789 Weilmünster, Germany
Company contact
Contact persons
KE
Kevin Endres
