Overview

About ZSO Zerspanungs- und Systemtechnik GmbH

Who we are

ZSO sees itself as a competent supplier and service provider in the metal Zerpanung (turning, milling, grinding) and component assembly. In the area of contract manufacturing (turning, milling, grinding and surface treatment), we offer our services from small series to medium runs with great variety. Here, the annual volumes of 5,000 St. can (with high complexity, Dreh-/Frästeil 50 min processing time) vary up to 1.4 million St. (simple turned part, about 1.5 min. Processing time). The possible workpiece sizes reach the maximum diameter of 400 mm when turning. In radial grooves on the outer contour may occur reduction of the workpiece diameter. During milling, we can work with our machining centers cube sizes up to 1000 mm. We also perform desired by impermeability tests also. The company ZSO GmbH is a company of senata GmbH (www.senata.de), an owner-managed medium-sized companies with a high share of equity.

1 / 2

2 / 2

Oberstaufen, Germany

Member since 2009

Employees50 - 100

Certificates2

Turnover10 - 20 Mil.

Year of foundation1997

Competencies

Technologies

Turning

Technologies	Lotsize	Length	Diameter	Weight
Turning	200–15,000	5–1,200 mm	15–400 mm	—
Automatic turning (bar)	500–100,000	5–100 mm	18–65 mm	—
Full-range turning (including milling)	200–5,000	20–500 mm	20–400 mm	—
Hard turning	200–10,000	5–500 mm	15–400 mm	—
Shaft machining	200–5,000	100–1,000 mm	20–250 mm	0–40 kg

Machining (Extruded Profiles)

Technologies	Width	Height	Weight
Machining of extruded sections	30–200 mm	30–200 mm	0–50 kg

Jigmaking

Technologies	Length	Width	Height	Weight
Drilling / milling jigs	30–1,000 mm	30–1,000 mm	30–1,300 mm	0–250 kg
Assembly jigs	30–1,000 mm	30–1,000 mm	30–1,300 mm	0–250 kg
Clamping devices	30–1,000 mm	30–1,000 mm	30–1,300 mm	0–250 kg

Assembly

Technologies	Weight
Mechanical assembly	0–20 kg

Measuring & Testing

Technologies	Length	Width	Height	Diameter	Weight
Measuring / testing	30–1,000 mm	30–1,000 mm	30–1,000 mm	20–400 mm	0–125 kg

Finishing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
External cylindrical grinding	200–5,000	20–1,000 mm	—	—	20–250 mm	0–50 kg
Internal cylindrical grinding	200–5,000	20–150 mm	—	—	20–300 mm	—
Centreless grinding	200–10,000	20–450 mm	—	—	10–100 mm	0–25 kg
Circular honing - internal	200–5,000	20–150 mm	20–100 mm	20–100 mm	20–150 mm	0–10 kg
Surface grinding machine	200–5,000	5–1,000 mm	20–400 mm	20–500 mm	—	0–100 kg
Profile grinding	200–5,000	5–1,000 mm	20–400 mm	20–500 mm	20–250 mm	—
Rotofinishing, barrel finishing	200–10,000	50–500 mm	50–300 mm	50–300 mm	—	—

Milling

Technologies	Lotsize	Length	Width	Height	Weight
Milling	500–200,000	100–900 mm	100–900 mm	100–900 mm	0–100 kg
5-axis milling machines	100–500 k	0–500 mm	250–1,000 mm	from 100 mm	—

Drilling / Sawing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Sawing	200–10,000	10–1,500 mm	20–420 mm	20–420 mm	20–420 mm	—
Drilling / threading / tapping	200–10,000	30–1,000 mm	30–1,000 mm	30–1,000 mm	—	0–100 kg

Materials

Steel

Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelCold extruding steel

Cast metals

Cast steelCast iron

Heavy metals

Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloys

Advanced Materials

Nickel alloy (Inconel, Monel, Hastelloy)

Sintered materials

Metal powder for formed parts

Light metals

Aluminium and aluminium alloysTitanium and titanium alloys
