Alfred Schnüttgen GmbH

Germany, 57368 Lennestadt

Overview

About Alfred Schnüttgen GmbH

Who we are

Features Quality Management zertfiziert according to ISO / TS 16949:2002 including ISO 9001:2000 Measurement: Zeiss CNC 3D coordinate measuring machine, Mitutoyo 2D metrology Production range: Stamped, pressed and drawn parts, assembly, welding joints, joints Materials: Varieties: steel, stainless steel, aluminum, brass Dimensions: Coil: Bandwidth up to 800mm - strap thickness up to 6mm - Weight 5.000kg to Customers: Automotive, electrical, construction, camping and leisure industry, child safety Machine types: Stamping presses, eccentric presses, hydraulic presses, Orbital, MAG-welding robots, press welding machines, stud welding machines Dimensions: Punching machines: 40 - 400 tonnes Eccentric: 10 - 160t Hydraulic Presses: 40 - 160to Own tool: Wire EDM, sinker EDM, CNC milling, drilling, grinding Development and design: CAD - CAM System VISI-CAD Interfaces: DXF, IGES, VDA, CATIA V4, Parasolid Data exchange: E-mail, Odette

Lennestadt, Germany

Member since 2003

Premium Member since 2022

Employees20 - 50

Certificates4

Turnover5 - 10 Mil.

Year of foundation1956

Marketing documents

IATF 16949 ISO 14001 ISO 9001 ZDM_AlfredSchnuettgenGmbH_Dez22.pdfPDF File

Competencies

Technologies

Sheet Metal Forming (Stamping, Deep-drawing)

Technologies	Lotsize	Length	Width	Height	Diameter	Material thickness
Punching / pressing (Out-of-tool)	10–5 M	5–1,200 mm	5–800 mm	—	—	0–6 mm
Stamping and bending machine (Bihler)	1–10 M	5–500 mm	10–600 mm	—	—	0.5–6 mm
Deep-drawing	10–100 k	0–400 mm	10–600 mm	0–200 mm	—	0.5–6 mm
Spinning	10–100 k	—	—	—	5–750 mm	5–1,000 mm

Welding

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Inert gas shielded arc welding (MIG/MAG)	100–100,000	1–1,500 mm	1–1,000 mm	1–250 mm	—	0–750 kg	—
Laser-beam welding	1–10 M	0–400 mm	10–600 mm	0–300 mm	0.5–100 mm	0–25 kg	—
Robot welding	1–100 k	1–1,500 mm	1–750 mm	1–750 mm	—	0–750 kg	—
Spot welding	100–100,000	—	—	—	—	—	0.1–15 mm
Stud welding	100–100,000	—	—	—	—	—	—
Projection welding	5,000–5 M	—	—	—	—	—	0.5–6 mm
Friction welding	1–10 M	0–400 mm	—	—	—	—	—
Friction stir welding	1–10 M	0–500 mm	—	—	—	—	—

Cutting dies / deep drawing dies

Technologies	Length	Width	Height	Weight
Punching / Cutting tools	10–2,500 mm	10–1,500 mm	10–1,500 mm	0–750 kg
Follow-on composite tools	10–2,500 mm	10–1,500 mm	10–1,500 mm	0–750 kg
Fineblanking tools	10–2,500 mm	10–1,500 mm	10–1,500 mm	0–750 kg
Deep-drawing dies	10–2,500 mm	10–1,500 mm	10–1,500 mm	0–750 kg
Die replacement / wearing part manufacturing	—	—	—	—

Measuring & Testing

Technologies	Length	Width	Height	Diameter	Weight
Measuring / testing	1–2,500 mm	1–1,500 mm	1–1,500 mm	1–750 mm	0–750 kg

Assembly

Technologies	Weight
Mechanical assembly	0–250 kg
Electromechanical assembly	0–250 kg

Sheet Metal Processing

Technologies	Lotsize	Length	Material thickness
Bending / folding	5,000–5 M	500–1,000 mm	1–5 mm

Assembly Group Manufacturing

Technologies	Lotsize	Length	Width	Material thickness
Riveting	1–100 k	1–750 mm	1–750 mm	0.5–25 mm

Finishing

Technologies	Lotsize	Length	Width	Height	Weight
Surface grinding machine	1–100 k	1–750 mm	1–750 mm	1–750 mm	0–250 kg

Materials

Natural materials

Wood/timberRock

Non-metal inorganic materials

CeramicsGlassConcreteCast mineralsGraphite

Precious metals

SilverGoldPlatinumOther precious metals

Plastics/synthetic materials

ThermoplasticsThermosetsElastomersSilocone (LSR)Natural and vulcanised rubberGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materials

Cast metals

Cast steelCast iron

Advanced Materials

Nickel alloy (Inconel, Monel, Hastelloy)

Sintered materials

Metal powder for formed partsMetal powder for hard metal

Steel

Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel

Light metals

Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys

Heavy metals

Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloysSolder

Industries

Aerospace and aviation industryAutomation and control engineeringChemical industryAir conditioning, refrigeration and ventilation industryPackaging industryLighting industryOffice machinery and suppliesPaper and printing machinery industryDrive and gear engineeringMedical technologyApparatus engineeringFurniture industrySpecial purpose machinery manufacturingFittings engineeringPower generation and transmission industryMeasurement and control technique, laboratory equipmentMachine tool manufacturingPrecision engineering, mechatronics and opticsHousehold appliance industryMilitary engineeringAutomotive and vehicle constructionElectrical industryMechanical engineering
