Entwicklung und Fertigung Eßbach GmbH&Co.KG

Germany, 09599 Freiberg

Overview

About Entwicklung und Fertigung Eßbach GmbH&Co.KG

Who we are

The company developing and manufacturing Eßbach was founded in Berthelsdorf 1999. Since April 2007, we relocated our headquarters to Brand-Erbisdorf. Here are covering an area of 750m ² various machining centers, design workstations and above average well-trained staff available with which we can also realize your tasks! Our high quality standards are certified by our certification to DIN ISO 9001. Examples of our products you can found in our website www.efe-essbach.de. Our main pillar is the development, production and distribution of heat sinks for power electronics. In addition to liquid cooling body systems based Unicool we also manufacture air-cooling systems of the body or combined devices after the system coldplate. Of course, we adjust the devices on your required specifications. Customers who use our products or benefits, include Siemens, Bosch, Baumuller, Bonfiglioli Vectron GmbH and Lust Antriebstechnik GmbH. In addition to the production of heat sinks, we operate a small special engineering. With this we are able to manufacture high quality facilities capable of over CAD design and CAD / CAM Interfaces. Thus, several different labeling systems to the standard product labeling including PDC connection were realized in our home. The investments are made entirely with control, and CNC-axes and delivered. Our customers can be found among others in the field of automotive and supply industry. Examples are: - Test benches for drive spindles with data acquisition - Labeling systems with freely programmable CNC axes 800x600x400 - Marking gear parts with interface to the PPS system - Devices for assembly and testing purposes - Molds for aluminum cast parts up to sizes of 800mm, including processing of castings when required - Special coolant systems for machine tools With our technology, we are able to realize customer-specific solutions, including the manufacture of parts and assemblies.Our machinery, we have expanded to operate and in particular the following machines: - 1 CNC machining centers with tool change 2000x800x800mm, internal cooling and swivel head - 1 CNC machining center 1000x500x400mm with tool changes and internal cooling - 1 CNC machining centers with tool change 500x400x400mm and NC rotary table - 1 universal CNC milling machine 800x400x400 (vertical and horizontal) - 1 CNC lathe, diameter 300mm long and 300 - Conventional turning up to 1000mm long - NC mandrel tube bending machine to D 26x2mm VA tube - Korundstrahlkabine for VA materials - Edelstahlbeizeinrichtung inside and outside - TIG welding workplace The CNC machines are connected to our CAD / CAM system and thus to work in a position to meet your or our drawings. Again, we have customers such as Heidelberger Druckmaschinen AG, Deckel Maho, Samputensili GmbH, Bharat Forge Aluminum GmbH & Co.KG or Licatec GmbH.

Freiberg, Germany

Member since 2009

Premium Member since 2025

Employees10 - 20

Certificates2

Turnover1 - 5 Mil.

Year of foundation1999

Competencies

Technologies

Jigmaking

Technologies	Length	Width	Height	Diameter	Weight	Material thickness
Drilling / milling jigs	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Gauges	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Measuring / testing jigs	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Assembly jigs	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Welding jigs	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Clamping devices	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm

Pipe & Tube Manufacturing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Pipe bending	1–1,000	100–6,000 mm	from 0 mm	from 0 mm	1–26 mm	from 0 kg	0.1–3 mm

Turning

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Turning	1–1,000	1–1,000 mm	from 0 mm	from 0 mm	1–400 mm	from 0 kg	from 0 mm
Automatic turning (bar)	1–500	0–800 mm	—	—	10–100 mm	—	—
Full-range turning (including milling)	1–1,000	5–500 mm	—	—	5–350 mm	—	—

Welded constructions / Structural Steelwork

Technologies	Length	Width	Height	Weight
Welded constructions (weldments)	0–2,500 mm	0–2,500 mm	0–2,500 mm	0–500 kg

Machining (Plastics & Rubber)

Technologies	Lotsize	Length	Width	Height	Diameter
Turning	1–500	0–750 mm	—	—	0–450 mm
Milling	1–500	0–2,000 mm	0–2,000 mm	0–750 mm	—

Casting

Technologies	Lotsize	Length	Width	Height	Weight
Machine moulding (sand casting)	1–5,000	from 0 mm	from 0 mm	from 0 mm	from 0 kg
Gravity die casting	1–500	0–750 mm	0–750 mm	0–500 mm	0–500 kg
Low-pressure casting	0–500	0–750 mm	0–750 mm	0–500 mm	0–500 kg
Hand moulding (sand casting)	0–500	0–750 mm	0–750 mm	0–500 mm	0–500 kg

Mechanical Engineering

Technologies	Lotsize	Length	Width	Height	Weight
Mechanical engineering	0–100	0–2,000 mm	0–750 mm	0–750 mm	0–1,000 kg
Apparatus engineering	0–100	0–2,000 mm	0–750 mm	0–750 mm	0–1,000 kg

Assembly

Technologies	Weight
Mechanical assembly	0–1,000 kg
Industrial / On-site-assembly	0–1,000 kg

Measuring & Testing

Technologies	Length	Width	Height	Diameter	Weight
Measuring / testing	0–1,000 mm	0–1,000 mm	0–1,000 mm	0–1,000 mm	0–500 kg

Tubes and pipes (assembled)

Technologies	Lotsize	Diameter
Hydraulic pipes	1–100	0–60 mm
Hydraulic tubes	1–100	0–60 mm
Industrial tubes	1–500	0–60 mm

Mould construction

Technologies	Length	Width	Height	Diameter	Weight	Material thickness
Pressure die cast molds	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Gravity casting moulds	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Modelmaking	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Squeeze moulds	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Vacuum deep-drawing moulds	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm
Extrusion dies	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm

Welding

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Inert gas shielded arc welding (TIG)	1–1,000	1–1,000 mm	1–1,000 mm	1–1,000 mm	1–1,000 mm	0–1 kg	1–100 mm

Surface Treatment

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Blacking	1–500	0–500 mm	0–500 mm	0–500 mm	—	0–100 kg	—
Electroplating	0–100	0–500 mm	0–500 mm	0–500 mm	—	0–150 kg	—
Sand blasting	1–1,000	1–500 mm	1–500 mm	1–500 mm	from 0 mm	0–100 kg	from 0 mm

Milling

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Milling	1–99 M	20–800 mm	50–2,000 mm	50–800 mm	from 0 mm	0–1 kg	from 0 mm
5-axis milling machines	1–99 M	20–800 mm	50–800 mm	50–800 mm	—	0–500 kg	—
Full-range milling (including turning)	1–99 M	20–750 mm	50–750 mm	50–750 mm	15–450 mm	—	—
HSC milling	1–99 M	20–800 mm	50–2,000 mm	50–800 mm	from 0 mm	0–1 kg	from 0 mm

Drilling / Sawing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Sawing	1–500	0–400 mm	0–400 mm	0–400 mm	0–400 mm	—	—
Drilling / threading / tapping	1–1,000	1–800 mm	1–2,000 mm	1–800 mm	from 0 mm	0–1 kg	from 0 mm

Finishing

Technologies	Lotsize	Length	Width	Height
Rotofinishing, barrel finishing	1–1,000	0–500 mm	0–500 mm	0–500 mm

Materials

Advanced Materials

Nickel alloy (Inconel, Monel, Hastelloy)

Cast metals

Cast steelCast iron

Light metals

Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys

Plastics/synthetic materials

ThermoplasticsThermosetsElastomersSilocone (LSR)Natural and vulcanised rubberGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materials

Steel

Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel

Precious metals

SilverGoldPlatinumOther precious metals

Heavy metals

Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloysSolder

Natural materials

Wood/timberRock

Sintered materials

Metal powder for formed partsMetal powder for hard metal

Non-metal inorganic materials

CeramicsGlassConcreteCast mineralsGraphite

Industries

Drive and gear engineeringSpecial purpose machinery manufacturingMachine tool manufacturingRailway and rail vehicles industryBuilding, agricultural and forestry machinery manufacturingFittings engineeringApparatus engineeringMechanical engineeringPrecision engineering, mechatronics and opticsAir conditioning, refrigeration and ventilation industryPlant engineering and construction

+3 moreShow less

Certificates

ISO 9001:2015

ISO 14001

Parts & Machines

Machinery (1)

VMC30

Drilling / threading / tappingHSC milling+1

ManufacturerDECKEL MAHO

Control-

Year of Construction2007

1 / 1

VMC30

ManufacturerDECKEL MAHO

Control-

Year of Construction2007

Technology

Drilling / threading / tappingHSC millingMilling

1 Machinery

Drilling / threading / tapping1

HSC milling1

Milling1
