Modell- und Formenbau J. Gördes e.K.

Germany, 59929 Brilon

Overview

About Modell- und Formenbau J. Gördes e.K.

Who we are

We from the model and mold construction J. Gördes produce since 1989 molds, devices, prototypes and foundry models on the highest level. Our aim is to provide our customers with the highest level of quality and dimensional accuracy in the form of our products in order to best support the customer processes. In this way, we create added value in the entire following production chain. In addition, we are available with our entire know-how for our customers and also bring us far beyond the actual mold making. From the very beginning, we understand our customer relationships as long-term partnerships in which we can develop together in order to achieve the greatest possible added value on both sides. The decisive factors for customer satisfaction are essentially the following aspects: • Documented dimensional accuracy • Production quality • Handling in the manufacturing process of the customers • Fast and competent advice and order processing • On-time delivery All employees are involved in the continuous improvement process to achieve the highest possible quality standards, and this ensures day after day that all the knowledge and experience contribute to the sustainable development of our products. In addition to our customers and employees, our suppliers are also part of the quality philosophy. Through long-term cooperation and continuous exchange of experience with them, we ensure consistently high quality and further development of our products. Likewise, we keep up to date with the latest technology through lively exchange with innovative suppliers. With this quality policy we pursue the following goals: • a high level of customer satisfaction in terms of the quality of our services and products. • the lasting assurance of high quality at all stages of the work process through careful planning, preparation and implementation of all necessary actions • the consistent application of preventive quality assurance measures to minimize or avoid the occurrence of errors. • securing the organizational conditions to ensure smooth and close cooperation of all employees of the company permanently. • Compliance with all customer requirements and legal obligations Our quality management is defined in a handbook and corresponding applicable documents and thus binding for all employees of the company.

Brilon, Germany

Member since 2019

Employees10 - 20

Certificates1

Year of foundation1989

Competencies

Technologies

Cutting dies / deep drawing dies

Technologies	Length	Width	Height	Weight
Punching / Cutting tools	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Follow-on composite tools	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Fineblanking tools	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Deep-drawing dies	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Trimming	0–550 mm	0–1,600 mm	0–1,000 mm	0–2,500 kg
Die replacement / wearing part manufacturing	—	—	—	—
Impact extrusion dies	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Embossing / swage dies	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Rod extrusion dies	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg

Mould construction

Technologies	Length	Width	Height	Weight
Injection moulds	100–1,000 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Pressure die cast molds	100–1,600 mm	100–1,000 mm	100–550 mm	0–2,500 kg
Gravity casting moulds	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Modelmaking	0–2,500 mm	0–2,500 mm	0–2,500 mm	0–2,500 kg
Foam molds	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Squeeze moulds	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Vacuum deep-drawing moulds	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Forging dies	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Sintering	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Extrusion dies	0–1,600 mm	0–1,000 mm	0–550 mm	0–2,500 kg
Blow moulds	1–1,600 mm	1–1,000 mm	1–550 mm	0–2,500 kg

Jigmaking

Technologies	Length	Width	Height	Weight
Drilling / milling jigs	0–550 mm	0–1,600 mm	0–1,000 mm	0–2,500 kg
Gauges	0–550 mm	0–1,600 mm	0–1,000 mm	0–2,500 kg
Measuring / testing jigs	0–550 mm	0–1,600 mm	0–1,000 mm	0–2,500 kg
Assembly jigs	0–550 mm	0–1,600 mm	0–1,000 mm	0–2,500 kg
Clamping devices	0–550 mm	0–1,600 mm	0–1,000 mm	0–2,500 kg

Milling

Technologies	Lotsize	Length	Width	Height
Milling	1–100	0–550 mm	0–1,600 mm	0–1,000 mm
5-axis milling machines	1–100	0–550 mm	0–650 mm	0–650 mm
Form milling (3 D)	1–100	0–550 mm	0–1,600 mm	0–1,000 mm

Additive Manufacturing

Technologies	Lotsize	Length	Width	Height
Selective laser sintering	1–100	0–610 mm	0–350 mm	0–350 mm

Materials

Light metals

Aluminium and aluminium alloys

Natural materials

Wood/timberRock

Heavy metals

Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloys

Plastics/synthetic materials

ThermoplasticsAcrylic (PMMA)High performance plasticThermosetsElastomersSilocone (LSR)Natural and vulcanised rubberGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materialsWood-Plastic-Composites (WPC)Natural Fibre Composites (NFC)

Steel

Case hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel
