Schwarz Systems GmbH

Germany, 72280 Dornstetten

Competencies

Technologies

Welding

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Inert gas shielded arc welding (MIG/MAG)	1–500	1–10,000 mm	1–10,000 mm	1–10,000 mm	1–10,000 mm	0–10,000 kg	1–100 mm
Inert gas shielded arc welding (Plasma)	1–500	1–30,000 mm	1–1,000 mm	1–3,000 mm	1–3,000 mm	0–100,000 kg	1–70 mm
Inert gas shielded arc welding (TIG)	1–500	1–4,000 mm	1–3,000 mm	1–4,000 mm	1–4,000 mm	0–20,000 kg	0.5–100 mm
Robot welding	1–100 k	1–2,000 mm	1–2,000 mm	1–2,000 mm	from 0 mm	0–1,000 kg	from 0 mm
Spot welding	1–3,000	—	—	—	—	—	1–50 mm
Manual electrode welding	1–500	1–10,000 mm	1–10,000 mm	1–10,000 mm	1–10,000 mm	0–10,000 kg	1–10,000 mm
Submerged-arc welding	1–1,000	100–3,000 mm	50–2,000 mm	50–2,000 mm	250–5,000 mm	0–10,000 kg	3–100 mm
Stud welding	1–3,000	—	—	—	—	—	—

Sheet Metal Processing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Laser cutting 2D	1–100 k	1–3,000 mm	1–1,500 mm	from 0 mm	from 0 mm	0–1,500 kg	0.5–25 mm
Bending / folding	1–2,000	1–3,000 mm	—	—	—	—	1–20 mm
Plate rolling / bending	1–5,000	—	1–3,000 mm	—	—	—	1–70 mm
Plate straightening	0–3,000	—	1–3,000 mm	—	—	—	1–70 mm
Shearing (rectangular blank/strip)	1–5,000	from 0 mm	from 0 mm	from 0 mm	from 0 mm	from 0 kg	0.5–12 mm

Assembly

Technologies	Length	Width	Height	Diameter	Weight	Material thickness
Mechanical assembly	from 0 mm	from 0 mm	from 0 mm	from 0 mm	0–1,000 kg	from 0 mm
Electromechanical assembly	from 0 mm	from 0 mm	from 0 mm	from 0 mm	0–1,000 kg	from 0 mm

Turning

Technologies	Lotsize	Length	Diameter
Turning	1–3,000	0–1,000 mm	20–300 mm
Full-range turning (including milling)	1–3,000	0–1,000 mm	20–300 mm

Welded constructions / Structural Steelwork

Technologies	Length	Width	Height	Weight
Welded constructions (weldments)	1–30,000 mm	1–3,000 mm	1–6,000 mm	0–100,000 kg
Machine frames / bases / racks	1–30,000 mm	1–3,000 mm	1–6,000 mm	0–100,000 kg

Measuring & Testing

Technologies	Length	Width	Height	Diameter	Weight
Measuring / testing	1–30,000 mm	1–3,000 mm	1–6,000 mm	1–3,000 mm	0–100,000 kg

Mechanical Engineering

Technologies	Lotsize	Length	Width	Height	Weight
Mechanical engineering	1–3,000	1–30,000 mm	1–3,000 mm	1–6,000 mm	0–100,000 kg
Hydraulic engineering	1–3,000	1–30,000 mm	1–3,000 mm	1–6,000 mm	0–100,000 kg
Pneumatic engineering	1–3,000	1–30,000 mm	1–3,000 mm	1–6,000 mm	0–100,000 kg
Apparatus engineering	1–1,000	10–10,000 mm	10–10,000 mm	10–10,000 mm	0–10,000 kg
Tool building	1–3,000	1–30,000 mm	1–3,000 mm	1–6,000 mm	0–100,000 kg
Handling technology	1–3,000	1–30,000 mm	1–3,000 mm	1–6,500 mm	0–100,000 kg

Surface Treatment

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Surfacing / build-up welding	1–1,000	1–30,000 mm	1–3,000 mm	1–6,000 mm	1–3,000 mm	0–100,000 kg	1–70 mm
Pickling	1–3,000	1–30,000 mm	1–3,000 mm	1–6,000 mm	—	0–100,000 kg	—
Electropolishing	1–3,000	1–30,000 mm	1–3,000 mm	1–6,000 mm	—	—	—
Rotofinishing, barrel finishing	1–3,000	1–300 mm	1–300 mm	1–300 mm	—	—	—
Parts cleaning/degreasing	—	1–30,000 mm	1–3,000 mm	1–6,000 mm	—	0–100,000 kg	—

Sheet Metal Forming (Stamping, Deep-drawing)

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Spinning	1–3,000	from 0 mm	from 0 mm	from 0 mm	40–1,500 mm	from 0 kg	0.5–10 mm
Roll forming	1–3,000	1–2,000 mm	1–1,000 mm	—	—	—	1–50 mm

Milling

Technologies	Lotsize	Length	Width	Height	Diameter
Milling	1–1,000	1–30,000 mm	1–6,500 mm	1–6,500 mm	—
5-axis milling machines	1–3,000	1–30,000 mm	1–3,000 mm	1–6,500 mm	—
Form milling (3 D)	1–1,000	1–30,000 mm	1–7,000 mm	1–7,000 mm	—
Full-range milling (including turning)	1–3,000	1–30,000 mm	1–3,000 mm	1–6,500 mm	1–400 mm

Jigmaking

Technologies	Length	Width	Height	Weight
Welding jigs	1–30,000 mm	1–3,000 mm	1–6,000 mm	0–100,000 kg

Finishing

Technologies	Lotsize	Length	Width	Height	Weight	Material thickness
Belt grinding	1–3,000	—	1–3,000 mm	—	—	1–50 mm
Shot blasting	1–3,000	1–30,000 mm	1–3,000 mm	1–6,000 mm	0–100,000 kg	—

Materials

Light metals

Aluminium and aluminium alloysTitanium and titanium alloys

Steel

Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steel

Advanced Materials

Nickel alloy (Inconel, Monel, Hastelloy)

Industries

Special purpose machinery manufacturingMedical technologyMechanical engineeringChemical industryApparatus engineeringClean room technologyAerospace and aviation industryBoiler, container and tank construction Packaging industryBuilding, agricultural and forestry machinery manufacturingPlant engineering and construction

+3 moreShow less

Certificates

ISO 9001:2015

DIN EN 1090

DIN 18800-7:2008 Class A-C (minor welding cert.)

DIN 18800-7:2008 Class D/E (major welding cert.)
