About Werkzeugtechnik Niederstetten GmbH & Co. KG

Who we are

Werkzeugtechnik Niederstetten GmbH & Co KG sees itself as a reliable full-service supplier in the area of precision parts and forming technology. As a company of the international Würth Group, we are already a competent partner for well-known industrial companies in Germany and abroad from a wide variety of industries. From advice to simulation & design to the tool ready for series production - with us you get everything from a single source! We also manufacture precision parts in single and small series production based on 3D data sets and according to your individual wishes. In addition to the well-known production processes such as CNC turning and grinding, 5-axis simultaneous and HSC milling as well as spark erosion, we at WTN rely on new, innovative technologies such as "Precise Electrochemical Metalworking", or PECM for short. At WTN, we not only have all the technical requirements to process the entire range of materials from soft to hard. With our 100 employees, you will primarily come across concentrated know-how for the satisfactory implementation of your projects.

1 / 2

2 / 2

Niederstetten, Germany

Member since 2001

Employees50 - 100

Certificates1

Turnover10 - 20 Mil.

Year of foundation1996

Competencies

Technologies

Turning

Technologies	Lotsize	Length	Diameter
Turning	1–1,000	0–1,300 mm	0–380 mm
Full-range turning (including milling)	1–1,000	0–450 mm	0–350 mm
Hard turning	1–1,000	0–950 mm	0–260 mm
Centering / end facing	1–1,000	0–500 mm	0–300 mm

Etching and Spark Erosion

Technologies	Lotsize	Length	Width	Height	Weight
Spark erosion wire cutting	1–1,000	0–500 mm	0–350 mm	0–250 mm	0–50 kg
Spark erosion countersinking	1–1,000	0–300 mm	0–300 mm	0–250 mm	0–50 kg

Mechanical Engineering

Technologies	Lotsize	Length	Width	Height	Weight
Mechanical engineering	1–100	0–500 mm	0–500 mm	0–500 mm	0–100 kg
Hydraulic engineering	0–100	0–500 mm	0–500 mm	0–500 mm	0–100 kg
Pneumatic engineering	1–100	0–500 mm	0–500 mm	0–500 mm	0–100 kg
Apparatus engineering	1–100	0–500 mm	0–500 mm	0–500 mm	0–100 kg
Tool building	0–100	0–500 mm	0–500 mm	0–500 mm	0–100 kg
Handling technology	0–100	0–500 mm	0–500 mm	0–500 mm	0–100 kg

Mould construction

Technologies	Length	Width	Height	Weight
Injection moulds	0–350 mm	0–350 mm	0–350 mm	0–50 kg
Pressure die cast molds	0–350 mm	0–350 mm	0–350 mm	0–50 kg
Modelmaking	1–500 mm	1–500 mm	1–500 mm	0–100 kg
Foam molds	0–350 mm	0–350 mm	0–350 mm	0–50 kg
Squeeze moulds	0–350 mm	0–350 mm	0–350 mm	0–50 kg
Vacuum deep-drawing moulds	0–350 mm	0–350 mm	0–350 mm	0–50 kg
Forging dies	0–350 mm	0–350 mm	0–350 mm	0–50 kg
Sintering	0–350 mm	0–350 mm	0–350 mm	0–50 kg
Extrusion dies	0–350 mm	0–350 mm	0–350 mm	0–50 kg
Blow moulds	0–350 mm	0–350 mm	0–350 mm	0–50 kg

Jigmaking

Technologies	Length	Width	Height	Weight
Drilling / milling jigs	0–550 mm	0–550 mm	0–550 mm	0–100 kg
Gauges	0–500 mm	0–500 mm	0–500 mm	0–100 kg
Measuring / testing jigs	0–500 mm	0–500 mm	0–500 mm	0–100 kg
Assembly jigs	0–500 mm	0–500 mm	0–500 mm	0–100 kg
Welding jigs	0–500 mm	0–500 mm	0–500 mm	0–100 kg
Clamping devices	0–500 mm	0–500 mm	0–500 mm	0–100 kg

Measuring & Testing

Technologies	Length	Width	Height	Diameter	Weight
Measuring / testing	0–400 mm	0–400 mm	0–400 mm	0–400 mm	0–35 kg

Milling

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Milling	1–1,000	1–750 mm	1–750 mm	1–500 mm	—	—
5-axis milling machines	1–1,000	1–750 mm	1–750 mm	1–500 mm	—	—
Form milling (3 D)	1–1,000	1–750 mm	1–750 mm	1–500 mm	—	—
Full-range milling (including turning)	1–1,000	1–500 mm	1–300 mm	1–300 mm	1–300 mm	—
HSC milling	1–2,000	1–350 mm	1–350 mm	1–200 mm	—	0–20 kg
Engraver milling	1–2,000	1–350 mm	1–350 mm	1–200 mm	1–350 mm	0–20 kg

Cutting dies / deep drawing dies

Technologies
Die replacement / wearing part manufacturing

Additive Manufacturing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
3D printing (general)	1–5,000	0–275 mm	0–275 mm	0–380 mm	—	—	—
Selective Laser Melting (SLM)	—	1–275 mm	1–275 mm	1–380 mm	1–275 mm	0–25 kg	1–2 mm

Labelling / marking

Technologies	Lotsize	Length	Width	Height	Diameter
Laser marking / Laser inscription	1–500	0–450 mm	0–450 mm	0–300 mm	0–450 mm

Surface Treatment

Technologies	Lotsize	Length	Width	Height	Weight
Sand blasting	1–500	0–300 mm	0–300 mm	0–300 mm	0–15 kg

Materials

Advanced Materials

Nickel alloy (Inconel, Monel, Hastelloy)Carbide

Steel

Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel

Heavy metals

Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloys

Light metals

Aluminium and aluminium alloysTitanium and titanium alloys

Sintered materials

Metal powder for formed partsMetal powder for hard metal

Plastics/synthetic materials

ThermoplasticsAcrylic (PMMA)High performance plasticThermosetsElastomersGlass fibre-reinforced plasticCarbon fibre-reinforced plasticParticle reinforced composite materials

Cast metals

Cast steelCast iron

Precious metals

Other precious metals

Non-metal inorganic materials

Graphite

Industries

Paper and printing machinery industryPower generation and transmission industryMeasurement and control technique, laboratory equipmentTelecommunication industryHydraulic and pneumatic industryConstruction and architectural suppliesPlant engineering and constructionMining and tunnel engineeringSpecial purpose machinery manufacturingDrive and gear engineeringFittings engineeringLighting industryChemical industryMechanical engineeringElectrical industryRailway and rail vehicles industryAutomotive and vehicle constructionApparatus engineeringFurniture industryMilitary engineeringClean room technologyMachine tool manufacturingHousehold appliance industryAerospace and aviation industryBuilding, agricultural and forestry machinery manufacturingPackaging industryAir conditioning, refrigeration and ventilation industryMedical technologyAutomation and control engineeringPrecision engineering, mechatronics and optics

+22 moreShow less
