Volantes GmbH

Germany, 91166 Georgensgmünd

Overview

About Volantes GmbH

Who we are

producer of castings and forging products; in steel, stainless steel, DUPLEX, cast iron (GJS, GJL), alumina-, magnesia- copper alloys, wear-resistance materials, NI-hard, heat-resistance materials, Hastelloy X, Inconel 625, super alloys; coating , heat-treatment and CNC-machining of own products and of external materials; assemby; certificated factories (ISO 9001, ISO/TS 16949); three own offices in China, one in India; from there our engineers control the factories regarding process schedule, quality and delivery times storage located in China, India and Germany

Georgensgmünd, Germany

Member since 2017

Employees20 - 50

Certificates2

Turnover5 - 10 Mil.

Year of foundation2019/2003

Marketing documents

Präzisionsguss_Groitl_-_Präsentation.pdfPDF File Organigramm_Praezisionsguss-Groitl.pdfPDF File PgG-Prototypen-Gussteile.pdfPDF File Warmfester-Stahlguss-PraezisionsgussGroitl.pdfPDF File Volantes/China-3D-printing-equipment

Competencies

Technologies

Casting

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Machine moulding (sand casting)	1,000–10 M	10–1,000 mm	10–1,000 mm	10–900 mm	—	0–5,000 kg
Gravity die casting	1,000–10 M	50–1,250 mm	50–1,250 mm	50–1,250 mm	—	0–150 kg
Pressure die casting	500–100,000	10–750 mm	10–750 mm	10–750 mm	—	0–15,000 kg
Investment casting	1,000–10 M	5–1,750 mm	5–1,750 mm	5–1,750 mm	—	0–75 kg
Low-pressure casting	1,000–10 M	25–1,250 mm	25–1,250 mm	25–1,250 mm	—	0–75 kg
Hand moulding (sand casting)	1,000–10 M	10–5,000 mm	10–5,000 mm	10–5,000 mm	—	0–1,000,000 kg
Centrifugal casting	1,000–10 M	500–7,500 mm	—	—	25–1,550 mm	0–5,500 kg

Solid Forming

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Drop forging	1,000–10 M	—	—	—	—	0–250 kg
Bar extrusion	500–1 M	500–10,000,000 mm	10–2,500 mm	10–2,500 mm	10–2,500 mm	—
Open die forging	1–10 M	—	—	—	—	0–50,000 kg

Sintering & Powder Pressing

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Sintering	1,500–10 M	1–350 mm	1–350 mm	1–350 mm	1–350 mm	0–35 kg
Metal injection moulding (MIM)	10,000–10 M	1–75 mm	1–75 mm	1–75 mm	—	0–10 kg

Gear Making

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Cylindrical gear / spur gear	1,000–10 M	10–1,250 mm	—	—	10–1,250 mm	—
Internal teeth	1,000–10 M	10–5,000 mm	—	—	10–5,000 mm	0–10,000 kg
Bevel gear wheel	1,000–10 M	10–2,500 mm	—	—	10–2,500 mm	0–10,000 kg
Sprocket (wheel)	1,000–10 M	10–2,500 mm	—	—	10–2,500 mm	0–10,000 kg
Cogged belt pulley	1,000–10 M	10–2,500 mm	—	—	10–2,500 mm	0–10,000 kg
Rack (toothed)	1,000–10 M	100–10,000 mm	10–1,000 mm	10–1,000 mm	10–1,250 mm	0–10,000 kg
Worm gear	1,000–10 M	10–2,500 mm	—	—	10–2,500 mm	0–10,000 kg

Threading

Technologies	Lotsize	Length	Diameter	Weight
Thread rolling	1,000–10 M	2–500 mm	0.5–150 mm	—
Thread grinding	1,000–10 M	5–250 mm	1–150 mm	0–50 kg
Thread whirling	from 10,000	5–250 mm	1–25 mm	0–5 kg
Worm milling	50–10 M	50–5,000 mm	5–500 mm	0–2,500 kg
Worm rolling	1,000–10 M	100–2,500 mm	25–500 mm	—
Worm grinding	1,000–10 M	50–1,250 mm	25–500 mm	0–1,500 kg

Welding

Technologies	Lotsize	Length	Width	Height	Diameter	Weight	Material thickness
Inert gas shielded arc welding (MIG/MAG)	1,000–10,000	50–4,000 mm	50–4,000 mm	50–10,000 mm	—	0–5,000 kg	—
Inert gas shielded arc welding (Plasma)	1,000–10,000	10–4,000 mm	50–4,000 mm	50–10,000 mm	5–2,000 mm	0–5,000 kg	1–50 mm
Inert gas shielded arc welding (TIG)	1,000–10,000	10–4,000 mm	50–4,000 mm	50–10,000 mm	—	0–5,000 kg	—
Laser-beam welding	1,000–100,000	10–5,000 mm	10–5,000 mm	10–2,500 mm	5–2,500 mm	0–100,000 kg	—
Spot welding	500–10,000	—	—	—	—	—	0.5–50 mm
Manual electrode welding	500–10,000	50–4,000 mm	50–4,000 mm	50–10,000 mm	5–100 mm	0–5,000 kg	1–100 mm
Stud welding	1,000–10,000	—	—	—	—	—	—
Soldering	1,000–10,000	50–4,000 mm	50–4,000 mm	50–10,000 mm	5–2,000 mm	0–5,000 kg	—
Friction welding	1,000–10,000	10–4,000 mm	—	—	—	—	—
Friction stir welding	1,000–10,000	10–4,000 mm	—	—	—	—	—

Welded constructions / Structural Steelwork

Technologies	Length	Width	Height	Weight
Welded constructions (weldments)	50–4,000 mm	50–4,000 mm	50–10,000 mm	0–5,000 kg
Machine frames / bases / racks	50–4,000 mm	50–4,000 mm	50–10,000 mm	0–5,000 kg

Turning

Technologies	Lotsize	Length	Width	Height	Diameter	Weight
Turning	1,000–100,000	5–2,500 mm	—	—	1–750 mm	—
Automatic turning (bar)	1,000–150,000	250–7,500 mm	—	—	10–750 mm	—
Full-range turning (including milling)	1,000–100,000	10–2,500 mm	—	—	5–1,500 mm	—
Hard turning	1,000–100,000	10–750 mm	—	—	1–250 mm	—
Broaching	500–50,000	100–2,500 mm	—	—	100–2,500 mm	—
Deep-hole drilling	1,000–100,000	10–1,250 mm	10–1,250 mm	10–1,250 mm	5–1,250 mm	0–10,000 kg
Shaft machining	100–100,000	100–12,500 mm	—	—	25–750 mm	0–5,000 kg

Sheet Metal Forming (Stamping, Deep-drawing)

Technologies	Lotsize	Length	Width	Height	Diameter	Material thickness
Punching / pressing (Out-of-tool)	1,000–100,000	50–1,500 mm	50–1,500 mm	—	—	0.1–10 mm
Deep-drawing	1,000–100,000	25–500 mm	25–560 mm	25–750 mm	—	0.5–5 mm
Fineblanking / pressing	1,000–100,000	50–5,000 mm	50–5,000 mm	—	—	—
Spinning	5,000–500,000	—	—	—	5–750 mm	0.1–5 mm
Roll forming	1,000–50,000	250–5,000 mm	100–5,000 mm	—	—	0.1–8 mm

Injection Moulding, Extruding

Technologies	Lotsize	Length	Width	Height	Weight
Injection moulding	1,000–25,000	1–750 mm	1–750 mm	1–750 mm	0–15 kg
Injection-mould around inserts	500–5,000	10–750 mm	10–750 mm	10–750 mm	0–15 kg
Foaming	1,000–25,000	10–750 mm	10–750 mm	10–750 mm	—

Wire & Spring Bending

Technologies	Lotsize	Diameter
Wire bending	1,000–50,000	0.5–25 mm
Spring bending	1,000–50,000	0.1–15 mm

Pipe & Tube Manufacturing

Technologies	Lotsize	Length	Diameter	Material thickness
Pipe bending	500–15,000	100–1,500 mm	10–750 mm	0.5–8 mm
Pipe forming	1,000–15,000	100–1,500 mm	100–1,500 mm	—

Cable Preparation

Technologies	Diameter
Cable preparation	100–2,500 mm

Sheet Metal Processing

Technologies	Lotsize	Length	Width	Height	Weight	Material thickness
Laser cutting 3D	1,000–100,000	50–5,000 mm	50–5,000 mm	50–5,000 mm	0–2,500 kg	0.1–12 mm
Bending / folding	500–100,000	25–2,500 mm	—	—	—	0.1–100 mm
Punching / nibbling	1,000–1 M	50–50,000 mm	50–5,000 mm	—	—	0.1–8 mm
Combined forming laser cutting / punching	1,000–10,000	50–5,000 mm	50–5,000 mm	—	—	0.1–15 mm
Laser cutting, tube & section	500–50,000	50–2,500 mm	50–2,500 mm	50–2,500 mm	—	0.1–12 mm
Plate rolling / bending	500–500,000	—	5–5,000 mm	—	—	0.1–50 mm

Tubes and pipes (assembled)

Technologies	Diameter
Industrial tubes	10–250 mm

Additive Manufacturing

Technologies	Lotsize	Length	Width	Height
Metal laser sintering	1–250	50–500 mm	50–500 mm	50–750 mm
Selective laser sintering	1–100	10–490 mm	10–490 mm	10–490 mm

Materials

Non-metal inorganic materials

CeramicsGraphite

Steel

Structural steelCase hardening/tempering steelStainless steel (rust-proof V2A)Stainless steel (rust-proof V4A)Free-cutting/mild steelTool steelSpring steelCold extruding steel

Advanced Materials

Nickel alloy (Inconel, Monel, Hastelloy)CarbideSilicium

Plastics/synthetic materials

ThermoplasticsAcrylic (PMMA)ThermosetsElastomersSilocone (LSR)Natural and vulcanised rubber

Light metals

Aluminium and aluminium alloysMagnesium and magnesium alloysTitanium and titanium alloys

Cast metals

Cast steelCast iron

Heavy metals

Copper-zinc alloys (brass)Copper and copper alloysZinc and zinc alloysSolder

Sintered materials

Metal powder for formed partsMetal powder for hard metal

Industries

Mechanical engineering

Certificates

ISO 9001:2015

ISO-TS 16949:2009

Contact

Location

Main locationLohwiesenweg 5A, 91166 Georgensgmünd, Germany

This map is hosted on Google Maps. See
privacy policy.

Further locationsheadquarters: Georgensgmünd/GERMANY offices China: Ningbo, Qingdao offices Vietnam: Hanoi, Saigon (HoChiMinh city) Lager/warehouse: Qingdao/CN, Hanoi/VN, Pleinfeld/GERMANY

Company contact

Contact persons

Andreas Moll

Volker Groitl

Aileen Zhong
