Materials A demand-sorted material storage provides the conditions for short delivery times, maximum flexibility and punctuality. Also, the materials used, the quality plays a decisive role: For use only high-quality cold-rolled strips reputable, certified mills come. Materials are processed from 0.05 to 10 mm thick and coil widths up to 400 mm. The range of materials includes the following qualities: Unalloyed steels according to DIN EN 10139 Hardening steels according to DIN EN 10132-2 Quenched and tempered steels according to DIN EN 10132-3 Spring steels according to DIN EN 10132-4 Stainless steels according to DIN EN 10088-2 Aluminum and wrought aluminum alloys according to DIN EN 485-1 and DIN EN 485-2 Copper and wrought copper alloys according to DIN EN 1652 and DIN EN 13599 Hard paper, pressboard, plastic Toolmaking The quality of the tool is one of the most important prerequisites for trouble-free and efficient punching parts production. The tooling of E. Winkemann manufactures tools with highest precision. The field of tool / construction is equipped among others with the following devices: 2D and 3D CAD systems in the field of tool design CNC EDM, drilling, milling and jig grinders with CAM connection The exchange of design data is in IGES or DXF format. For around 6000 are consequential, composite, flexural, and embossing tools or total cuts available. Stamping technology The stamping of E. Winkemann is equipped with a powerful machinery, responsive to the diverse areas of use and the materials to be processed. The machines range from mechanical or hydraulic punching machines and presses to various bending machines: Hydraulic machinery and punching machines (25 to 500 tons) Eccentric (10 to 35 tons) Hydraulic presses (15 to 200 tons) Punching and bending machines (up to 15) Stamping machines (up to 200) Fine blanking machines (up to 700) Fineblanking / cutting The fine blanking allows the production of precision parts with smooth cut surfaces and high dimensional accuracy. Costly rework can be omitted. Straight-cut percentage up to 100%. The fine blanking machines with max. 320 tons pressing force can process material thicknesses up to about 7 mm. In addition, there is also the possibility of products on fine blanking machines with max. To process 700 tons press force. Flatting If the required thickness tolerance or flatness can not be achieved by cold rolling with the primary materials with a thickness of 0.8 mm, the parts are ground flat. The result is a thickness tolerance and flatness of ± 0.005 mm. High demands of these parameters are primarily intended for products which are used for example in units and transmissions. Representing this are start-up, passport and shims to call. Fine grinding Slices or moldings with a thickness of 0.8 mm and an outer diameter 4.0 mm könnnen be honed for maximum precision requirements with a tolerance of ± 0.001 mm. Post For the post-processing of the products are modern, electronically controlled and linked compensation and processing equipment available: Fully automatic compensation system with process data acquisition and batch documentation Program-controlled systems for automatic vibratory deburring Washing and cleaning equipment Machines and assembly equipment for drilling, tapping, riveting, stamping and assembling. Surfaces All parts ...

Fan art 40 years experience, top quality and a fair price-performance package. With commitment, the necessary know-how and innovative ideas, we specialize in fan such as axial fans, centrifugal fans and flat fan highest quality. The high-performance fans come in broadly diversified fields such as medicine, avionics, industrial and automotive markets each and every day their prowess. They are the enormously high standards exemplary justice of reliability of these areas. ______________________________________________________________________ Enclosures Robust, individually and German at the highest level of engineering. Thus one could describe the case of Bedek enclosure technology. More than 650 modifiable models are available here to choose from. Using the latest technology will be produced at Bedek high-end housing excellence performance. With the Bedek ENGINEERING service, we support you professionally and personally from the idea, through development and construction to finished product in all phases of your project. _______________________________________________________________________ Precision resistors A look into the future. Maximum reliability with maximum resilience make the custom-made precision resistors become the world leader. Application areas such as medical, aerospace and military speak for themselves. Bedek introduces zertfiziertes Precision center and can provide tailor-made film resistors for your needs within 24 hours. TCR of 0.2 ppm / ° C. ESD immunity> 25KV Tolerance: 0.005%

Establishment in 1874, Today, innovative Blechbearbeitungszentrum: Engineering Toolmaking Forming System supplier diecast Joining / welding Surface Technology Assembly / assemblies Logistics Flat, process-oriented organization, own large machinery 1 August 2010: Move to the new Büro-/Produktionsstätte: CO2-neutral building approximately 60 employees Customers at home and abroad

We as schoolboys stamping and forming GmbH + Co.KG working since 1846 as a supplier of metal processing. Finished and supply parts from various materials for industry and trade. Our product range extends from single pieces to medium series. Our manufacturing capabilities include: • CNC manufacturing to ᴓ 600 mm • high volume turned parts up to 24 mm ᴓ • own tool • Die cutting to 110 to • Welding TIG / MAG / Alu • individual trolley systems • Special Fittings We produce all kinds of fittings, stamping parts, stamping parts tool Falling or inlays in several steps. Also done in-house milling and turning as well as tool for the subsequent series production. We are happy to provide advice and practical help and guide you from the development to the finished part.

Over time, our company has developed from a craft business to a modern industrial company. Starting with shiny turning and milling tools made from natural diamonds to to cutting and grinding tools made of polycrystalline diamond (PCD) and cubic boron nitride (CBN). In order to meet the high demands of industry, our machines and measurement equipment are state of the art and are subject to continuous development. Our high-precision tools are used in the automotive and aircraft industries, in the electrical and optical industries and in mechanical engineering.

precision mechanical processing, rectification, 3d milling, 3d printing.

AICHER TOOL has experience in the manufacture of injection molds for over 50 years. From micro molds up to a size of 450 x 600 mm, the portfolio ranges. This purpose we have in addition to the Stardardmaschinenausrüstung as milling center, Sodick wire EDM a WEILER CNC lathe and a JUNG-grinding machine as well as a HANSEN 500 E EDM machine available, with which we are also able to carry out or to work with most electrodes largest reductions. Design and construction We offer our customers, of course, the possibility of their data in all standard and many special formats (eg IGES, DWG, STEP, .....) to deliver to us. Customers still have an idea but no precise idea about the appearance of the article, we are happy to support in terms of design and our technical advice with our years of expertise. With our CAD system "SolidWorks" we are to create a lifelike image of your future product capable. PLASTIC TECHNOLOGY From the construction in our house to the finished molded part ..... You have the idea - we put you together with you to: Assembly - together develop the idea further - design - develop technical features and functionalities From Prototype to Production We use for creating photo-realistic views to the design of the tools the specially designed program "SolidWorks". To program the machine is us "Esprit" and "SolidCAM" is available. Both programs guarantee fast and accurate production. For inquiries and information, simply sat down with us. We also have experience in prototype construction in the area Rapid Prototyping Laser sintering Stereolithography Product optimization With our CAD software SolidWorks, we are able to create animations, which can detect possible conflicts in advance.This optimization of the product without prototype or consuming rework is possible.

With our 45 process-driven processing machinery (injection molding) with clamping forces up to 4000 KN, about 2,000 high-precision technical plastic parts and rubber and rubber-metal connections are made at the time. Except for PVC, we provide you with all plastics market available. The designs of about 100 customers at home and abroad are construction and materials meet transposed into molds and tools and manufactured by injection molding. Follow-up work such as assembling, printing or conversion can also be performed. An operating data acquisition system (PDA) system with visualisiertem console and a computer-assisted quality control (CAQ system) according to the guidelines of the DIN EN ISO 9001:2000 (quality) as well as raw materials and materials testing equipment ensure the desired high quality standard. The own 3D CAD design and its own tool and mold (3D-CAM) contribute to this continuous quality production. We also have our own lathes and automatic lathes department (6-axis CNC Landrehautomaten) to produce precision turned parts and lathe parts. Main products: / Technical Functional parts made of plastic (injection) to about 2.000 grams Encapsulation of inserts, shafts, pulleys and rollers for paper transport TPU-X processing (crosslinked TPU) TSG (foam injection molding) Metal substitution Compact, insert, and 2-component technology, component manufacturing, printed housing Rubber-metal compounds (vulcanization) Tooling Turned parts and lathe parts

We manufacture molds according to drawing patterns and using CAD data to a Size of max. 296x396 eischl.Konstruktion. We would be happy CNC milling services also in the 3D area from Traverse max.400mm Erosion work we do to max.Werkstückgröße of 250 mm As a small operation, we produce very cost effective.

The company Duro-Tec Kunststofftechnik GmbH, located in the Middle Franconian town of Veitsbronn, was established in Erlangen at the end of 2009. Due to an insolvency of the previously resident company Volland / Erlangen (mold making & plastics technology), the company Duro-Tec was able to create an experienced team from this family business, which has existed for over 115 years, and support it with technical innovations. After Mr. Joachim Peiler helped the company Duro-Tec Kunststofftechnik GmbH to new strength after the takeover of the company Volland, Mrs. Susanne Peiler took over the company in 2021 as sole managing director. The core business of Duro-Tec is the production of complex and high-precision plastic parts. Whether in the initial consultation, the final implementation or modification of your articles, we are always able to carry out a fast and competent project.

From design to prototype and produce line, a comprehensive company Whatever the field of activity of a company, icts leaders from now on Should Have an obligation to do everything to AVOID leakage or dispersions customers possible. Review: The most common strategy is to position Itself on the market as a supplier of "global solutions", a generic term for a wide-range of services and benefits. The engineering office specializes in. technical hand by injection, CREOPP-TEC positions on the market All which can not only Provide the general solution to the original medical equipment manufacturing in the medical industry, the purpose aussi automotive accessories, toys, electronics, defense or cosmetics. Experienced technical experience over the years is to get all the additional knowledge. The company Operates since 1996 for the design and manufacture the Following The tools of all the field (injection / over molded, unscrewing, double injection for parallel and vertical 2K injection molding machine Blow molding gold...). If CREOPP-TEC subsequently assembled on a network of French molders, it aussi offers a low-cost industry with China Directly with our Chinese partner. Do not be dependent on technology goal INSTEAD take the best of each, this is the credo of the engineering office. From the stage of designing hand-TEC CREOPP CONSIDERS the eco-design and Provides referenced materials before the next simulation's phase. The rheological software Cadmould Rapid Could optimize the injection process and control the deformation. Not long after, in the stage of rapid prototyping and adjust the tool, development and industrialization icts on injection machine from 50 to 1000 tons, the company Will show the extent of icts different skills. For Having a final visual effect Quickly, the customers of CREOPP-TEC POSSESS lots of ways: such as stereo-lithography HR (High Resolution), the selected laser sintering (polyamide, Duraform HST gold Duraform Flex A6 steel or aluminum) or odd CNC rapid prototype, Vacuum Casting and RIM (Reaction Injection Molding - Process shaping thermosetting plastics).Finally, working on the industrialization stage encompasses all stages, it includes the assembly, painting, packaging, various checks and tests.

With a presence of over 27 years in the German market, we are committed to providing high-quality services and paying attention to every detail of our projects. We are recognized for our professionalism and seriousness, the high quality level of the products and services offered, as well as the prompt response to inquiries and the delivery of ordered products and services. Services and expertise: Design and Verification: We offer comprehensive PCB design and verification services. Our team of specialists helps you develop optimal technical solutions for your specific needs. Digitization: We stay up-to-date with the latest technologies in digitizing documentation and processes to ensure that your PCBs and data are managed efficiently and accurately. Pre-production: Our experience in PCB verification is one of our main advantages. We ensure that every aspect is considered before the actual fabrication of printed circuits. Highest Quality PCB Execution: The quality of the PCBs we provide is recognized and appreciated in the Romanian printed circuit market. We adhere to IPC 600 and IEC 326 standards, and our specialists are certified in accordance with the IPC-A-610 standard. Quality Commitment: With pride, we guarantee excellent quality! Our qualified staff, UL certification, and ISO certification are evidence of our commitment to maintaining high-quality standards to meet the expectations of our customers. No matter how complex or simple your projects are, we are here to help you realize them. With an experienced team in data preparation for manufacturing, we guarantee efficiency and precision in every project. This allows us to produce PCBs ranging from the simplest to the most complex, with up to 28 layers. Over time, we have had the opportunity to produce printed circuits in all fields of activity, collaborating with both local firms and multinational companies. That is why we are proud to develop customized PCB solutions that perfectly meet your needs and offer you materials of the highest quality. From FR-4, Aluminum, Teflon, Copper core, Polyamide, and Rogers to Flexible PCBs and Rigid-Flex PCBs, we have the expertise and resources to use various specialized materials according to your requirements.

From prototype to finished part series form. Our spectrum ranges from CNC turning over sinker EDM up to 3 - to 5-axis simultaneous milling. We develop the optimal solution for their company. Ranging from the simple pattern shape to 1000 T tools with Aufspannmaßen of 1200 mm, including cold runners and handling equipment for the loading and unloading. For us, no challenge is too great. Our production range includes forms for simple rubber parts, rubber - metal compounds, plastic parts and 2-component plastic tools. Manufacture of tools for the rubber, plastics industry. 3-5 axis milling, HSC milling. Tool size up to 1000x1200mm

Dr. Franke GmbH & Co. KG are nationally and internationally as recognized partner in the field of stamping and forming. The field-proven know-how is based on a many years of experience from the beginnings of plate lock- technology to modern technology in sheet metal forming. Here you have a dedicated development and Staff team is available that with sound knowledge a wide range of manufacturing dominated alternatives. ° STAMPING ° DEEPDRAWING ° FINEBLANKING ° WELDING ° MOUNT ° COATING ° CONSTRUCTION ° TOOL ° PROTOTYPE With individual, custom manufacturing for large- and small series presents Dr. Franke GmbH & Co. KG is the constantly changing product and logistics requirements of the international industrial Only by Dr. Franke documented real customer focus.

Harald Berfelde GmbH Since more than 100 years, the Harald Berfelde GmbH produces technical plastic parts of all common thermoplastics with single or multi-component injection molding. Our portfolio contains: High-level tooling – from Design to volume production Research + Development Design, Simulation of products Development, prototyping Injection molding production Assembly + logistics Project management, interface to the customer

The tool Plettenberg, formerly Albert Biecker steel molds for more than 80 years, manufactures dies and tools for foreign and domestic forging industry. On an area of 12,000 m2 with nearly 70 employees dies for the small and medium range manufactured, which are made from special workpiece materials such as high quality coated hot work tool steels, füllgeschweißte dies and special steels for Titanschmiedungen. Tool holder and Großgesenke for the forging industry complement the extensive production program. The performance program is rounded off by an efficient contract manufacturing in the areas of milling, turning, engraving, grinding and quality control. Here the focus is on components of the medium to large weights. The available machines up to 25 tons (single piece weight) and, of course, edit.

The Japa GmbH was founded with a focus on CNC machines Installation / Commissioning and aluminum light crane system installation / distribution / handling devices of 2009. Since the beginning of 2014, we are working hard on our new assembly lines, retrofit of Conventional / CNC machines and contract manufacturing conventional and CNC. Special orders and design through us also part of our range.

Plastics molding plastic molding for third parties injection welding vibration and infrared overmoulding construction of plastic molds assembly of plastic polymers.
